India's Most Experienced Manufacturers,Suppliers and Exporter of Ansi b16.47 Flanges, Ansi b16.47 Weld neck Flanges, Ansi b16.47 Slip on Flanges, Ansi b16.47 Socket weld Flanges, Ansi b16.47 Blind Flanges, Ansi b16.47 Lapped joint Flanges, Ansi b16.47 Threaded Flange, Ansi b16.47 Plate Flange in India & UK

Ansi b16.47 Flanges

• Ansi b16.47 Flanges Dimensions
• ASME/ANSI B16.47 class 75
• ASME/ANSI B16.47 class 150
• ASME/ANSI B16.47 class 300
• ASME/ANSI B16.47 class 600
• ASME/ANSI B16.47 class 900
• Leading manufacturer of Ansi b16.47 Flanges
• Our Live Stock of Ansi b16.47 Flanges
• Ansi b16.47 Flanges Application

Specifications :-

Types Of Ansi b16.47 Flanges

•	Ansi b16.47 Forged Flanges	•	Ansi b16.47 High Hub Blinds Flanges
•	Ansi b16.47 Blind Flanges	•	Ansi b16.47 Spectacle Blinds Flanges
•	Ansi b16.47 Reducing Flanges	•	Ansi b16.47Loose Flanges
•	Ansi b16.47 Orifice Flanges	•	Ansi b16.47 RTJ Flanges
•	Ansi b16.47 Socket Weld Flanges	•	Ansi b16.47 Screwed Flanges
•	Ansi b16.47 Slip On Flanges	•	Ansi b16.47 Weld Neck Flanges
•	Ansi b16.47 Flat Flanges	•	Ansi b16.47 Flanges Facing Type & Finish
•	Ansi b16.47 Lapped Joint Flanges	•	Ansi b16.47 SORF Flanges
•	Ansi b16.47 SWRF Flanges	•	Ansi b16.47 Groove & Tongue Flanges
•	Ansi b16.47 Square Flanges	•	Ansi b16.47 Long Neck Weld Flanges
•	Ansi b16.47 Threaded Flanges	•	Ansi b16.47 Spades Ring Spacers Flanges
•	Ansi b16.47 Weld Neck Flanges Series A or B	•	Ansi b16.47 Ring Type Joint Flanges
•	Ansi b16.47 WNRF Flanges	•	Ansi b16.47 Weldo / Nipo Flanges
•	Ansi b16.47 Expander Flanges

ANSI B16.47 Flange Dimensional Sizes Weld Neck, ANSI Class 150, ASME B16.47 Series A, 1/16″ Raised Face (in)

The following is chart data for ANSI B16.47 Flange Dimensional Data Size table for 1/16″ Raised Face (in) :

Pipe Size (NPS)	Outside Diameter of Flange A	Diameter of Raised Face B	Thickness of Flange C	Diameter of Bore D	Diameter of Hub at Weld H	Diameter of Hub at Base J	Length of Hub K	Number of Bolt Holes	Diameter of Bolt Holes	Bolt Circle Diameter P	Approx. Weight (lb)
26	34 1/4	29 1/2	2 11/16	*	26	26 5/8	4 3/4	24	1 3/8	31 3/4	300
28	36 1/2	31 1/2	2 13/16	*	28	28 5/8	4 15/16	28	1 3/8	34	345
30	38 3/4	33 3/4	2 15/16	*	30	30 3/4	5 3/8	28	1 3/8	36	400
32	41 3/4	36	3 3/16	*	32	32 3/4	5 11/16	28	1 5/8	38 1/2	505
34	43 3/4	38	3 1/4	*	34	34 3/4	5 7/8	32	1 5/8	40 1/2	540
36	46	40 1/4	3 9/16	*	36	36 3/4	6 3/16	32	1 5/8	42 3/4	640
38	48 3/4	42 1/4	3 7/16	*	38	39	6 3/16	32	1 5/8	45 1/4	720
40	50 3/4	44 1/4	3 9/16	*	40	41	6 7/16	36	1 5/8	47 1/4	775
42	53	47	3 13/16	*	42	43	6 3/4	36	1 5/8	49 1/2	890
44	55 1/4	49	4	*	44	45	7	40	1 5/8	51 3/4	990
46	57 1/4	51	4 1/16	*	46	47 1/8	7 5/16	40	1 5/8	53 1/4	1060
48	59 1/2	53 1/2	10 1/4	*	48	49 1/8	7 9/16	44	1 5/8	56	1185
50	61 3/4	55 1/2	4 3/8	*	50	51 1/4	8	44	1 7/8	58 1/4	1270
52	64	57 1/2	4 9/16	*	52	53 1/4	8 1/4	44	1 7/8	60 1/2	1410
54	66 1/4	59 1/2	4 3/4	*	54	55 1/4	8 1/2	44	1 7/8	62 3/4	1585
56	68 3/4	62	4 7/8	*	56	57 3/8	9	48	1 7/8	65	1760
58	71	64	5 1/16	*	58	59 3/8	9 1/4	48	1 7/8	67 1/4	1915
60	73	66	5 3/16	*	60	61 3/8	9 7/16	52	1 7/8	69 1/4	2045

flange dimensions for pipes ranging 1/2″ to 24″ – in classes ranging 150 to 2500.

ASME B16.47 Series A/MSS SP-44 Class 150 WN

Norminal Pipe Size	O.D.of Flange, O	Min.Thick-ness of WN Flange, tf	Lenth Through Hub, Y	Diam. of Hub, X	Hub Diam. Top, A	Raised Fase Diam., R	Bore (XS)	Diam of Bolt Circle	No.of Bolt Holes	Diam.of Bolt Hole	Min.Fillet Radius, r1	Approxi-mate Weight kgs
26	870	66.7	119	676	660.4	749	635.0	806.4	24	34.9	10	149.41
28	925	69.9	124	727	711.2	800	685.8	863.6	28	34.9	11	169.16
30	985	73.1	135	781	762.0	857	736.6	914.2	28	34.9	11	199.94
32	1060	79.4	143	832	812.8	914	787.4	977.9	28	41.3	11	248.11
34	1110	81.0	148	883	863.6	965	838.2	1028.7	32	41.3	13	265.05
36	1170	88.9	156	933	914.4	1022	889.0	1085.8	32	41.3	13	316.63
38	1240	85.8	156	991	965.2	1073	939.8	1149.4	32	41.3	13	352.68
40	1290	88.9	162	1041	1016.0	1124	990.6	1200.2	36	41.3	13	378.89
42	1345	95.3	170	1092	1066.8	1194	1041.4	1257.3	36	41.3	13	431.30
44	1405	100.1	176	1143	1117.6	1245	1092.2	1314.4	40	41.3	13	484.41
46	1455	101.6	184	1197	1168.4	1295	1143.0	1365.2	40	41.3	13	516.92
48	1510	106.4	191	1248	1219.2	1359	1193.8	1422.4	44	41.3	13	567.68
50	1570	109.6	202	1302	1270.0	1410	1244.6	1479.6	44	47.6	13	617.00
52	1625	114.3	208	1353	1320.8	1461	1295.4	1536.7	44	47.6	13	677.24
54	1685	119.1	214	1403	1371.6	1511	1346.2	1593.8	44	47.6	13	752.92
56	1745	122.3	227	1457	1422.4	1575	1397.0	1651.0	48	47.6	13	827.71
58	1805	127.0	233	1508	1473.2	1626	1447.8	1708.2	48	47.6	13	914.15
60	1855	130.2	238	1559	1524.0	1676	1498.6	1759.0	52	47.6	13	959.11

ASME B16.47 Series B/API 605 Class 150 WN

Norminal Pipe Size	O.D.of Flange, O	Min.Thick-ness of WN Flange, tf	Lenth Through Hub, Y	Diam. of Hub, X	Hub Diam. Top, A	Raised Fase Diam., R	Bore (XS)	Diam of Bolt Circle	No.of Bolt Holes	Diam.of Bolt Hole	Min.Fillet Radius, r1	Approxi-mate Weight kgs
26	785	39.8	87	684	661.9	711	636.5	744.5	36	22.2	10	62.61
28	835	43.0	94	735	712.7	762	687.3	795.3	40	22.2	10	71.98
30	885	43.0	98	787	763.5	813	738.1	846.1	44	22.2	10	78.00
32	940	44.6	106	840	814.3	864	788.9	900.1	48	22.2	10	90.31
34	1005	47.7	109	892	865.1	921	839.7	957.3	40	25.4	10	109.16
36	1055	50.9	116	945	915.9	972	890.5	1009.6	44	25.4	10	122.69
38	1125	52.5	122	997	968.2	1022	942.8	1070.0	40	28.6	10	146.24
40	1175	54.1	127	1049	1019.0	1080	993.6	1120.8	44	28.6	10	158.37
42	1225	57.3	132	1102	1069.8	1130	1044.4	1171.6	48	28.6	11	174.09
44	1275	58.9	135	1153	1120.6	1181	1095.2	1222.4	52	28.6	11	185.45
46	1340	60.4	143	1205	1171.4	1235	1146.0	1248.3	40	31.8	11	217.52
48	1390	63.6	148	1257	1222.2	1289	1196.8	1335.1	44	31.8	11	235.84
50	1445	66.8	152	1308	1273.0	1340	1247.6	1385.9	4	31.8	11	277.60
52	1495	68.4	156	1360	1323.8	1391	1298.4	1436.7	52	31.8	11	274.80
54	1550	70.0	160	1413	1374.6	1441	1349.2	1492.2	56	31.8	11	298.15
56	1600	71.6	165	1465	1425.4	1492	1400.0	1543.0	60	31.8	14	315.74
58	1675	73.1	173	1516	1476.2	1543	1450.8	1611.3	48	34.9	14	375.36
60	1725	74.7	178	1570	1527.0	1600	1501.6	1662.1	52	34.9	14	397.93

ASME B16.47 Series A/MSS SP-44 Class 300 WN

Norminal Pipe Size	O.D.of Flange, O	Min.Thick-ness of WN Flange, tf	Lenth Through Hub, Y	Diam. of Hub, X	Hub Diam. Top, A	Raised Fase Diam., R	Bore (XS)	Diam of Bolt Circle	No.of Bolt Holes	Diam.of Bolt Hole	Min.Fillet Radius, r1	Approxi-mate Weight kgs
26	970	77.8	183	721	660.4	749	635.0	876.3	28	44.5	10	281.42
28	1035	84.2	195	775	711.2	800	685.8	939.8	28	44.5	11	341.50
30	1090	90.5	208	827	762.0	857	736.6	997.0	28	47.6	11	391.62
32	1150	96.9	221	881	812.8	914	787.4	1054.1	28	50.8	11	453.92
34	1205	100.1	230	937	863.6	965	838.2	1104.9	28	50.8	13	507.59
36	1270	103.2	240	991	914.4	1022	889.0	1168.4	32	54.0	13	566.57
38	1170	106.4	179	994	965.2	1029	939.8	1092.2	32	41.3	13	319.44
40	1240	112.8	192	1048	1016.0	1086	990.6	1155.7	32	44.5	13	386.54
42	1290	117.5	198	1099	1066.8	1137	1041.4	1206.5	32	44.5	13	420.71
44	1355	122.3	205	1149	1117.6	1194	1092.2	1263.6	32	47.6	13	480.07
46	1415	127.0	214	1203	1168.4	1245	1143.0	1320.8	28	50.8	13	544.96
48	1465	131.8	222	1254	1219.2	1302	1193.8	1371.6	32	50.8	13	580.44
50	1530	138.2	230	1305	1270.0	1359	1244.6	1428.8	32	54.0	13	660.93
52	1580	142.9	237	1356	1320.8	1410	1295.4	1479.6	32	54.0	13	708.91
54	1660	150.9	251	1410	1371.6	1467	1346.2	1549.4	28	60.3	13	863.02
56	1710	152.4	259	1464	1422.4	1518	1397.0	1600.2	28	60.3	13	909.29
58	1760	157.2	265	1514	1473.2	1575	1447.8	1651.0	32	60.3	13	952.75
60	1810	162.0	271	1565	1524.0	1626	1498.6	1701.8	32	60.3	13	1012.28

ASME B16.47 Series B / API 605 Class 300 WN

Norminal Pipe Size	O.D.of Flange, O	Min.Thick-ness of WN Flange, tf	Lenth Through Hub, Y	Diam. of Hub, X	Hub Diam. Top, A	Raised Fase Diam., R	Bore (XS)	Diam of Bolt Circle	No.of Bolt Holes	Diam.of Bolt Hole	Min.Fillet Radius, r1	Approxi-mate Weight kgs
26	865	87.4	168	702	665.2	737	639.8	803.3	32	34.9	14	192.17
28	920	87.4	148	756	716.0	787	690.6	857.2	36	34.9	14	201.54
30	990	92.1	156	813	768.4	845	743.0	920.8	36	38.1	14	244.39
32	1055	101.6	167	864	819.2	902	793.8	977.9	32	41.3	16	302.35
34	1110	101.6	171	918	870.0	953	844.6	1031.9	36	41.3	16	325.93
36	1170	101.6	179	965	920.8	1010	895.4	1089.0	32	44.5	16	360.30
38	1220	109.6	165	1016	971.6	1060	946.2	1139.0	36	44.5	16	387.36
40	1275	114.3	197	1067	1022.4	1114	997.0	1190.6	40	44.5	16	442.44
42	1335	117.5	203	1118	1074.7	1168	1049.3	1244.6	36	47.6	16	491.16
44	1385	125.5	213	1173	1125.5	1219	1100.1	1295.4	40	47.6	16	541.07
46	1460	127.0	221	1229	1176.3	1270	1150.9	1365.2	36	50.8	16	633.78
48	1510	127.0	222	1278	1227.1	1327	1201.7	1416.0	40	50.8	16	651.27
50	1560	136.6	233	1330	1277.9	1378	1252.5	1466.8	44	50.8	16	715.51
52	1615	141.3	241	1383	1328.7	1429	1303.3	1517.6	48	50.8	16	775.24
54	1675	135.0	238	1435	1379.5	1480	1354.1	1578.0	48	50.8	16	804.16
56	1765	152.4	267	1494	1430.3	1537	1404.9	1651.0	36	60.3	17	1071.01
58	1825	152.4	273	1548	1481.1	1594	1455.7	1712.9	40	60.3	17	1137.64
60	1880	149.3	270	1599	1557.3	1651	1531.9	1763.7	40	60.3	17	1071.78

ASME B16.47 Series B/API 605 Class 75 WN

Norminal Pipe Size	O.D.of Flange, O	Min.Thick-ness of WN Flange, tf	Lenth Through Hub, Y	Diam. of Hub, X	Hub Diam. Top, A	Raised Fase Diam., R	Bore (XS)	Diam of Bolt Circle	No.of Bolt Holes	Diam.of Bolt Hole	Min.Fillet Radius, r1	Approxi-mate Weight kgs
26	760	31.9	57	676	661.9	705	636.5	723.9	36	19.1	8	39.07
28	815	31.9	60	727	712.7	756	687.3	774.7	40	19.1	8	44.07
30	865	31.9	64	778	763.5	806	738.1	825.5	44	19.1	8	47.95
32	915	33.5	68	829	814.3	857	788.9	876.3	48	19.1	8	53.42
34	965	33.5	72	879	865.1	908	839.7	927.1	52	19.1	8	57.47
36	1035	35.0	84	935	915.9	965	890.5	992.2	40	22.2	10	76.71
38	1085	36.6	87	986	966.7	1016	941.3	1043.0	40	22.2	10	84.00
40	1135	36.6	91	1037	1017.5	1067	992.1	1093.8	44	22.2	10	89.46
42	1185	38.2	94	1087	1068.3	1118	1042.9	1144.6	48	22.2	10	96.40
44	1250	41.4	103	1140	1119.1	1175	1093.7	1203.3	36	25.4	10	120.21
46	1300	43.0	106	1191	1169.9	1226	1144.5	1254.1	40	25.4	10	128.88
48	1355	44.6	110	1241	1220.7	1276	1195.3	1304.9	44	25.4	10	141.53
50	1405	46.2	114	1294	1271.5	1327	1246.1	1355.7	44	25.4	10	153.33
52	1455	46.2	119	1345	1322.3	1378	1296.9	1409.7	48	25.4	10	161.29
54	1510	47.8	124	1397	1373.1	1429	1347.7	1460.5	48	25.4	10	178.43
56	1575	49.3	133	1451	1423.9	1486	1398.5	1520.8	40	28.6	11	209.87
58	1625	50.9	137	1502	1474.7	1537	1449.3	1571.6	44	28.6	11	222.53
60	1675	54.1	143	1553	1525.5	1588	1500.1	1622.4	44	28.6	11	241.99

ASME B16.47 Series A/MSS SP-44 Class 600 WN

Norminal Pipe Size	O.D.of Flange, O	Min.Thick-ness of WN Flange, tf	Lenth Through Hub, Y	Diam. of Hub, X	Hub Diam. Top, A	Raised Fase Diam., R	Bore (XS)	Diam of Bolt Circle	No.of Bolt Holes	Diam.of Bolt Hole	Min.Fillet Radius, r1	Approxi-mate Weight kgs
26	1015	108.0	222	748	660.4	749	635.0	914.4	28	50.8	13	441.66
28	1075	111.2	235	803	711.2	800	685.8	965.2	28	54.0	13	500.13
30	1130	114.3	248	862	762.0	857	736.6	1022.4	28	54.0	13	564.95
32	1195	117.5	260	918	812.0	914	786.6	1079.5	28	60.3	13	636.04
34	1245	120.7	270	973	863.6	965	838.2	1130.3	28	60.3	14	694.71
36	1315	123.9	283	1032	914.4	1022	889.0	1193.8	28	66.7	14	787.50
38	1270	152.4	254	1022	965.2	1054	939.8	1162.0	28	60.3	14	665.35
40	1320	158.8	264	1073	1016.0	1111	990.6	1212.8	32	60.3	14	713.76
42	1405	168.3	279	1127	1066.8	1168	1041.4	1282.7	28	66.7	14	887.56
44	1455	173.1	289	1181	1117.6	1226	1092.2	1333.5	32	66.7	14	939.98
46	1510	179.4	300	1235	1168.4	1276	1143.0	1390.6	32	66.7	14	1036.58
48	1595	189.0	316	1289	1219.2	1334	1193.8	1460.5	32	73.0	14	1236.72
50	1670	196.9	329	1343	1270.0	1384	1244.6	1524.0	28	79.4	14	1436.50
52	1720	203.2	337	1394	1320.8	1435	1295.4	1574.8	32	79.4	14	1504.69
54	1780	209.6	349	1448	1371.6	1492	1346.2	1632.0	32	79.4	14	1661.71
56	1855	217.5	362	1502	1422.4	1543	1397.0	1695.4	32	85.7	16	1867.92
58	1905	222.3	370	1553	1473.2	1600	1447.8	1746.2	32	85.7	16	1976.20
60	1995	233.4	389	1610	1524.0	1657	1498.6	1822.4	28	92.1	17	2378.47

ASME B16.47 Series B / API 605 Class 600 WN

Norminal Pipe Size	O.D.of Flange, O	Min.Thick-ness of WN Flange, tf	Lenth Through Hub, Y	Diam. of Hub, X	Hub Diam. Top, A	Raised Fase Diam., R	Bore (XS)	Diam of Bolt Circle	No.of Bolt Holes	Diam.of Bolt Hole	Min.Fillet Radius, r1	Approxi-mate Weight kgs
26	890	111.2	181	698	660.4	727	635.0	806.4	28	44.5	13	259.28
28	950	115.9	190	752	711.2	784	685.8	863.6	28	47.6	13	299.55
30	1020	125.5	205	806	762.0	841	736.6	927.1	28	50.8	13	372.00
32	1085	130.2	216	860	812.8	895	787.4	984.2	28	54.0	13	432.05
34	1160	141.3	233	914	863.6	953	838.2	1054.1	24	60.3	14	542.78
36	1215	146.1	243	968	914.4	1010	889.0	1104.9	28	60.3	14	593.49

ASME B16.47 Series A/MSS SP-44 Class 900 WN

Norminal Pipe Size	O.D.of Flange, O	Min.Thick-ness of WN Flange, tf	Lenth Through Hub, Y	Diam. of Hub, X	Hub Diam. Top, A	Raised Fase Diam., R	Bore (XS)	Diam of Bolt Circle	No.of Bolt Holes	Diam.of Bolt Hole	Min.Fillet Radius, r1	Approxi-mate Weight kgs
26	1085	139.7	286	775	660.4	749	635.0	952.5	20	73.0	11	683.01
28	1170	142.9	298	832	711.2	800	685.8	1022.4	20	79.4	13	808.16
30	1230	149.3	311	889	762.0	857	736.6	1085.8	20	79.4	13	924.60
32	1315	158.8	330	946	812.8	914	787.4	1155.7	20	85.7	13	1114.09
34	1395	165.1	349	1006	863.6	965	838.2	1225.6	20	92.1	14	1298.15
36	1460	171.5	362	1064	914.4	1022	889.0	1289.0	20	92.1	14	1472.04
38	1460	190.5	352	1073	965.2	1099	939.8	1289.0	20	92.1	19	1436.84
40	1510	196.9	364	1127	1016.0	1162	990.6	1339.8	24	92.1	21	1518.64
42	1560	206.4	371	1176	1066.0	1213	1040.6	1390.6	24	92.1	21	1654.33
44	1650	214.4	391	1235	1117.6	1270	1092.2	1463.7	24	98.4	22	1941.88
46	1735	225.5	411	1292	1168.4	1334	1143.0	1536.7	24	104.8	22	2261.24
48	1785	233.4	419	1343	1219.2	1384	1193.8	1587.5	24	104.8	24	2425.26

ASME B16.47 Series B / API 605 Class 900 WN

Norminal Pipe Size	O.D.of Flange, O	Min.Thick-ness of WN Flange, tf	Lenth Through Hub, Y	Diam. of Hub, X	Hub Diam. Top, A	Raised Fase Diam., R	Bore (XS)	Diam of Bolt Circle	No.of Bolt Holes	Diam.of Bolt Hole	Min.Fillet Radius, r1	Approxi-mate Weight kgs
26	1020	135.0	259	743	660.4	762	635.0	901.7	20	66.7	11	532.55
28	1105	147.7	276	797	711.2	819	685.8	971.6	20	73.0	13	673.44
30	1180	155.6	289	851	762.0	876	736.6	1035.0	20	79.4	13	793.39
32	1240	160.4	303	908	812.8	927	787.4	1092.2	20	79.4	13	899.59
34	1315	171.5	319	962	863.6	991	838.2	1155.7	20	85.7	14	1061.78
36	1345	173.1	325	1016	914.4	1029	889.0	1200.2	24	79.4	14	1070.53

Leading manufacturer of Ansi b16.47 Flanges

We also having stock of Ansi b16.47 Flanges & other Stainless Steel Flanges, Carbon Steel Flanges, Alloy Steel Flanges manufactured by :

Erne Fittings, Austria	Metal far, Italy	Lame S.R.l., Italy
BENKAN Corporation, Japan	BKL- Thai Benkan, Thailand	TecnoForge, Italy
Ulma, Spain	Mega, Italy	Melesi, Italy
Interfit, France	Raccortubi S.P.A., Italy

we are the distributor of the of these Brands. we also have the sales representative who can provide the proper information of these Brands & about Grades, material and sizes of Ansi b16.47 Flanges.

Our Live Stock of Ansi b16.47 Flanges

Click Here for Ansi b16.47 Weld Neck Flanges Live Stock

Click Here for Ansi b16.47 Forged Flanges Live Stock

Click Here for Ansi b16.47 Blind Flanges Live Stock

Ansi b16.47 Flanges Application

Ansi b16.47 Flanges uses in Oil and Gas Pipeline Ansi b16.47 Flanges uses in Chemical Industry Ansi b16.47 Flanges uses in Plumbing Ansi b16.47 Flanges uses in Oil & Gas Industry Ansi b16.47 Flanges uses in Water Supply Systems Ansi b16.47 Flanges uses in Paper & Pulp Industry

Ansi b16.47 Flanges uses in Power Plant Ansi b16.47 Flanges uses in Fabrication Industry Ansi b16.47 Flanges uses in General purpose applications Ansi b16.47 Flanges uses in Food Processing Industry Ansi b16.47 Flanges uses in Structural Pipe Ansi b16.47 Flanges uses in Heat Exchangers

Flanges :: Flange Standard, Fitting Standard, Pipe Standard, Valve Standard
ANSI Flange	DIN Flange	EN Flange
ASME Flange	JIS/KS Flange	GB Flange
GOST Flange	BS Flange	UNI / Api Flange
Flanges ::
Blind Flanges	Reducing Threaded Flanges	Lap Joint Flanges
Flange Gaskets	Threaded Flanges	Socketweld Flanges
Flanges Bolts	Ring Flange	Spectacle Blind Flanges
Weld Neck Flanges	Orifice Flange	Slip-On-Flanges
High Hub Blinds Flanges

Manufacturers And Suppliers Of Different Types Of Flanges listed Below

Forged Flanges	Blind Flanges	Slip on Flanges
Weld Neck Flanges	Lapped Joint Flanges	Threaded Flanges
Socket Weld Flanges	Long Weld Neck Flanges	Weldo / Nipo Flanges
Orifice Flanges	Reducing Flanges	Flat Flanges
Loose Flanges	RTJ Flanges	Sorf Flanges
Square Flanges	Swrf Flanges	Expander Flanges
Wnrf Flanges	Ring Type Joint Flanges	Groove & Tongue Flanges
High Hub Blinds Flanges	Spectacle Blind Flanges	Weld Neck Flanges A / B
Spades Ring Spacers Flanges	Screwed Flanges	Forging Facing Flanges

Cities We Deliver To

Riyadh, Faridabad, Courbevoie, Kolkata, Rajkot, Howrah, Atyrau, Petaling Jaya, Ankara, Ho Chi Minh City, Kanpur, Istanbul, Geoje-si, La Victoria, Ahmedabad, Los Angeles, Montreal, New Delhi, Granada, Jeddah, Aberdeen, Calgary, Nashik, London, Chandigarh, Hyderabad, Chiyoda, Milan, Gimhae-si, Mumbai, Kuala Lumpur, Muscat, Ranchi, Abu Dhabi, Jakarta, Ernakulam, Tehran, Vung Tau, Kuwait City, Surat, Sydney, Houston, Edmonton, Ludhiana, Pune, Port-of-Spain, Ulsan, Caracas, Coimbatore, Mexico City, Hanoi, Al Khobar, Pimpri-Chinchwad, Bangkok, Secunderabad, Vadodara, Jaipur, Perth, Chennai, Cairo, Karachi, New York, Gurgaon, Melbourne, Manama, Busan, Rio de Janeiro, Colombo, Bengaluru, Madrid, Indore, Toronto, Ahvaz, Dubai, Thiruvananthapuram, Bhopal, Brisbane, Nagpur, Sharjah, Al Jubail, Thane, Dammam, Singapore, Santiago, Haryana, Doha, Moscow, Lagos, Jamshedpur, Baroda, Visakhapatnam, Dallas, Lahore, Hong Kong, Seoul, Noida, Bogota, Algiers, Navi Mumbai

Countries We Deliver To

Indonesia, Hong Kong, Kenya, Trinidad & Tobago,Tunisia, Kuwait, Russia, Norway, Mongolia, Croatia, Tibet, Nigeria, Nepal, Czech Republic, Portugal, Spain, Turkey, Finland, Lebanon, Azerbaijan, France, Japan, South Korea, Libya, Bolivia, Iraq, United Arab Emirates, Germany, Saudi Arabia, Jordan, Zimbabwe, Netherlands, Bhutan, United States, Morocco, Switzerland, Austria, Puerto Rico, Lithuania, Sweden, Poland, Serbia, Romania, Denmark, Bulgaria, South Africa, Iran, China, Qatar, Nigeria, Bangladesh, Gambia, Slovakia, New Zealand, Peru, Canada, Yemen, Ireland, Sri Lanka, Philippines, Iran, Costa Rica, Ecuador, Mexico, Italy, United Kingdom, Belgium, Israel, Venezuela, Thailand, Angola, Estonia, Belarus, Brazil, Taiwan, Pakistan, Hungary, Vietnam, Australia, Afghanistan, Algeria, Kazakhstan, Gabon, Mexico, Poland, Bahrain, Malaysia, Greece, Macau, Chile, Singapore, Colombia, Oman, Chile, Namibia, Ukraine, Ghana, Argentina, India, Egypt

Ansi b16.47 Flanges with Test Certificate, Ansi b16.47 Flanges at dealer price, Ansi b16.47 Flanges in India , Ansi b16.47 Flanges Prices in India , Stainless Steel Pipe Fittings Stockist in India , Ansi b16.47 Flanges Supplier in India , Ansi b16.47 Flanges Exporter in India , Ansi b16.47 Flanges Manufacturer in India , Ansi b16.47 Flanges Distributor in India , Ansi b16.47 Flanges Trader in India , Ansi b16.47 Flanges Dealer in India , Ansi b16.47 Flanges Stockholder in India , Ansi b16.47 Flanges Importer in India. , Ansi b16.47 Flanges distributor in Mumbai , Ansi b16.47 Flanges with Test Certificate , Ansi b16.47 Flanges Manufacturer in Mumbai,Ansi b16.47 Flanges, best quality Ansi b16.47 Flanges, India’s largest Ansi b16.47 Flanges manufacturer, wide variety of Ansi b16.47 Flanges, Ansi b16.47 Flanges India, Ansi b16.47 Flanges distributor Mumbai, Ansi b16.47 Flanges traders, prime quality Ansi b16.47 Flanges, Source for Ansi b16.47 Flanges, specialize in Ansi b16.47 Flanges
