India's Most Experienced Manufacturers,Suppliers and Exporter of Flat Flanges, Carbon Steel Flat Flanges, Stainless Steel Flat Flanges, Alloy Steel Flat Flanges, Inconel Flat Flanges, Nickel Alloy Flat Flanges, Hastelloy Flat Flanges, Monel Flat Flanges,A182 Flat Flanges in India & UK

We are largest manufacturers of Flat Flanges & have huge stock of 304 Flat Flanges, 316 Flat Flanges, astm a105 Flat Flanges, astm a182 Flat Flanges as per asme / ansi B16.5 Flat flanges, ansi B16.47 Flat flanges, Din Flat flanges, jis Flat flanges & uni Flat flanges Standards

Best Price of Flat Flanges in all size, classes & dimensions like Class 150 Flat Flanges, Class 300 Flat Flanges, Class 600 Flat Flanges, Class 900 Flat Flanges, Class 1500 Flat Flanges & Class 2500 Flat Flanges,Astm A105 Flat Flanges,Astm A182 Flat Flanges As Per Asme / Ansi B16.5 Flat Flanges,Ansi 150 Flat Face Flange, Ansi B16.5 Flat Face Flange

Flat Flanges

Flat Flanges Price

Leading manufacturer of Flat Flanges

Our Live Stock of Flat Flanges

Flat Flanges Application

BS4505 Standard Flat Flanges, Stainless Steel Plate (PL) 101 Flat Flanges PN25 ASTM A815 UNS S31803/ F51/ S2205 Flat Flanges

Product Despriction

Product Name Flat Flanges Face Finish RF,FF,RTJ,TF,GF Size ½” (15 NB) to 48″ (1200NB) Standard ANSI ANSI B16.5 ASME B16.47 series A/B DIN DIN 2631 2573 2527 2565 2641 GOST GOST 12820-80,GOST 12821-80,Gost Blind EN EN1092-1:2002 JIS JIS B2220-2004, KS D3576, KS B6216,KS B1511-2007,JIS B2261; JIS B8210 BS BS4504,BS10 Table D/E UNI UNI 2253-67,UNI6091-67,UNI2276-67,UNI2280-67,UNI6089-67 SABS SABS 1123 Material ANSI CS A105/SA 105N,SS 304/304L,316/316L Alloy Steel: WHPY45/52/65/80 DIN CS RST37.2;S235JR SS 304/304L,316/316L GOST CS CT20;16MN;SS 304/304L,316/316L EN CS RST37.2;S235JR;C22.8SS 304/304L,316/316L JIS CS SS400,SF440,SS 304/304L, 316/316L BS CSRST37.2;S235JR;C22.8;Q235SS 304/304L,316/316L UNI CSRST37.2;S235JR;C22.8;Q235SS 304/304L,316/316L SABS CSRST37.2;S235JR;Q235;SS 304/304L,316/316L Pressure ANSI Class 150, 300, 600, 900, 1500 2500lbs DIN PN6,PN10,PN16,PN25,PN40,PN64,PN100 GOST PN6,PN10,PN16,PN25 EN PN6,PN10,PN16,PN25,PN40,PN64,PN100 JIS 1K,2K,5K,10K,16K,20K,30K,40K BS PN6,PN10,PN16,PN25,PN40,PN64,PN100 UNI PN6,PN10,PN16,PN25,PN40 SABS 600KPA,1000,1600,2500,4000 Size ANSI 1/2” – 60” DIN DN15-DN2000 GOST DN10-DN1600 EN DN15-DN2000 JIS 15A-1500A BS DN15-DN2000 UNI DN10-DN2000 SABS DN10-DN600 Coating varnish, yellow paint, anti-rust oil, galvanizing etc Usage Used for the connection of all kinds of pipeline to convey the water, steam, air, gas and oil Package Wooden cases/pallets Delivery Within 30 days Certificate TUV, ISO9001:2008 Stainless Steel Flat Flanges ASTM A182 F202, A 240 F 304, 304L, 304H, 316, 316L, 316Ti, 316LN, 310S, 317L, 321, 410, 420, 440C, 202, F904L Carbon Steel Flat Flanges ASTM / ASME A/SA 105 , ASTM / ASME A 350 , ASTM A 181 LF 2 / A516 Gr.70 A36, A694 F42, F46, F52, F60, F65, F70 Alloy Steel Flat Flanges ASTM / ASME A/SA 182 & A 387 F1, F5, F9, F11, F12, F22, F91 Duplex Steel Flat Flanges ASTM / ASME A/SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61 Pressure Class Ratings Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500 | PN6, PN10, PN16, PN25, PN40, PN64 etc. Specialize As per drawing Standard ANSI : ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48 ,JIS,DIN,BS4504,SABS1123,EN1092-1, UNI,AS2129,GOST-12820 DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673 B.S : BS4504 , BS4504, BS1560, BS10 Connection Type / Flange Face Type Ring Type Joint, Lap-Joint Face, Raised Face, Flat Face, Large Male-Female, Small Male-Female, Large Tongue & Groove, Small Tongue & Groove

ASME/ ANSI B16.5 Flat Pipe Flanges Manufacturing Materials :

Dimensions	Base Material	Pressure Rating
ASME B16.5	ASTM A182 (Forgings) ASTM A240 (Plate)	150#. 300#. 400#. 600#. 900#. 1500#. 2500#.
API 605	ASTM A182 (Forgings) ASTM A240 (Plate)	150#. 300#. 400#. 600#. 900#. 1500#. 2500#.
ASME B16.47series A & B	ASTM A182 (Forgings) ASTM A240 (Plate)	150#. 300#. 400#. 600#. 900#. 1500#. 2500#.
EN1092-1	ASTM A182 (Forgings)	PN2.5. PN6. PN10. PN16. PN25. PN40. PN63. PN100. PN160. PN250. PN320. PN400.
BS4504	BS970 (Bar)ASTM A240 (Plate) ASTM A182 (Forgings)	PN2.5. PN6. PN10. PN16. PN25. PN40. PN63. PN100. PN160.
BS10	BS970 (Bar)ASTM A240 (Plate) ASTM A182 (Forgings)

Typical Stainless Steel 18/8 Grade Designations:

ASTM	BS	DIN	EURONORM
304	304S15	X5 Cr Ni 18 10	1.4301
304L	304S11	X2 Cr Ni 18 9	1.4307
316	316S31	X5 Cr Ni Mo 17 12 2	1.4401
316L	316S11	X2 Cr Ni Mo 17 13 2	1.4404
321	321S31	X6 Cr Ni 18 10	1.4541
316Ti	320S31	X6 Cr Ni Mo Ti 17 12 2	1.4571
SMO	254SMO	X1 Cr Ni Mo Cu N 20 18 7	1.4547

Dimension and weight of DIN2503 PN40 Flat Flange

Nominal Pipe Size	Diameter of Pipe		Flange I.D	No. of holes	Flange Dia	Thk of Flange	Dia of Bolt Circle	Dia of Bolt Holes	Approx.Weight
DN	ISO	DIN	D5	BN	D	b	K	d2	KG/PCS
10	-	14	14.5	4	90	16	60	14	0.7
	17.2	-	17.7	4	90	16	60	14	0.69
15	-	20	21	4	95	16	65	14	0.77
	21.3	-	22	4	95	16	65	14	0.77
20	-	25	26	4	105	18	75	14	1.06
	26.9	-	27.6	4	105	18	75	14	1.05
25	-	30	31	4	115	18	85	14	1.27
	33.7	-	34.4	4	115	18	85	14	1.25
32	-	38	39	4	140	18	100	18	1.86
	42.4	-	43.1	4	140	18	100	18	1.83
40	-	44.5	45.5	4	150	18	110	18	2.12
	48.3	-	49	4	150	18	110	18	2.09
50	-	57	58.1	4	165	20	125	18	2.78
	60.3	-	61.1	4	165	20	125	18	2.74
65	76.1	-	77.1	8	185	22	145	18	3.48
80	88.9	-	90.3	8	200	24	160	18	4.33
100	-	108	109.6	8	235	24	190	22	5.82
	114.3	-	115.9	8	235	24	190	22	5.61
125	-	133	134.8	8	270	26	220	26	7.91
	139.7	-	141.6	8	270	26	220	26	7.6
150	-	159	161.1	8	300	28	250	26	10.12
	168.3	-	170.5	8	300	28	250	26	9.58
175	193.7	-	196.1	12	350	32	295	30	14.45
200	219.1	-	221.8	12	375	34	320	30	16.9
250	-	267	270.2	12	450	38	385	33	27.28
	273	-	276.2	12	450	38	385	33	26.51
300	323.9	-	327.6	16	515	42	450	33	36.38
350	355.6	-	359.7	16	580	46	510	36	52.83
	-	368	372.2	16	580	46	510	36	50.24
400	406.4	-	411	16	660	50	585	39	74.71
	-	419	423.7	16	660	50	585	39	71.44
500	508	-	513.6	20	755	52	670	42	86.87
600	610	-	616.5	20	890	54	795	48	121.84
700	711	-	716	24	995	58	900	48	150.93
800	813	-	818	24	1140	64	1030	56	219.08
900	914	-	920	28	1250	70	1140	56	271.16
1000	1016	-	1022	28	1360	78	1250	56	344.95

Leading manufacturer of Flat Flanges

We also having stock of Flat Flanges & other Stainless Steel Flanges, Carbon Steel Flanges, Alloy Steel Flanges manufactured by :

Erne Fittings, Austria	Metal far, Italy	Lame S.R.l., Italy
BENKAN Corporation, Japan	BKL- Thai Benkan, Thailand	TecnoForge, Italy
Ulma, Spain	Mega, Italy	Melesi, Italy
Interfit, France	Raccortubi S.P.A., Italy

we are the distributor of the of these Brands. we also have the sales representative who can provide the proper information of these Brands & about Grades, material and sizes of Flat Flanges.

Our Live Stock of Flat Flanges

Click Here for Stainless Steel Flat Flanges Live Stock

Click Here for Carbon Steel Flat Flanges Live Stock

Click Here for Alloy Steel Flat Flanges Live Stock

Flat Flanges Application

Flat Flanges uses in Oil and Gas Pipeline Flat Flanges uses in Chemical Industry Flat Flanges uses in Plumbing Flat Flanges uses in Oil & Gas Industry Flat Flanges uses in Water Supply Systems Flat Flanges uses in Paper & Pulp Industry

Flat Flanges uses in Power Plant Flat Flanges uses in Fabrication Industry Flat Flanges uses in General purpose applications Flat Flanges uses in Food Processing Industry Flat Flanges uses in Structural Pipe Flat Flanges uses in Heat Exchangers

Flanges :: Flange Standard, Fitting Standard, Pipe Standard, Valve Standard
ANSI Flange	DIN Flange	EN Flange
ASME Flange	JIS/KS Flange	GB Flange
GOST Flange	BS Flange	UNI / Api Flange
Flanges ::
Blind Flanges	Reducing Threaded Flanges	Lap Joint Flanges
Flange Gaskets	Threaded Flanges	Socketweld Flanges
Flanges Bolts	Ring Flange	Spectacle Blind Flanges
Weld Neck Flanges	Orifice Flange	Slip-On-Flanges
High Hub Blinds Flanges

We Stock All Different Types Of Flat Flanges at Updated Price

flat face flange b16.5 flat face flange bolt length flat face flange definition flat face flange design when to use flat face flange when use flat face flange why use a flat face flange flat face flange finish raised vs flat face flange use of flat face flanges pn16 flat face flange dimensions ansi 150 flat face flange ansi b16.5 flat face flange asa flat face flange asme class 150 flat face flange class 125 flat face flange class 150 flat face flange design of flat face flange flat face ansi flange flat face blind flange flat face carbon steel flanges flat face flange advantages flat face flange and raised face flange flat face flange application flat face flange asme flat face flange asme b16.5

flat face flanges standard flat face lap joint flange flat face orifice flange flat face pipe flange flat face slip on flange flat face slip on flanges flat face socket weld flange flat face threaded flange flat face weld neck flange jis flange flat face raised face or flat face flange what is a flat face flange flat face flange picture flat face flange raised face flat face flange ratings flat face flange specification flat face flange standards flat face flange surface finish flat face flange thickness flat face flange to raised face flange flat face flange uses flat face flange vs raised face flat face flange wiki flat face flange with raised face flange

flat face flange weight flat face pipe flange dimensions flat face slip on flange dimensions flat face socket weld flange dimensions flat face weld neck flange dimensions what is flat face flange ansi 125 flat face flange dimensions ansi 150 flat face flange dimensions ansi 150 lb flat face flange dimensions ansi b16.5 flat face flange dimensions ansi flat face flange dimensions asme b16.5 flat face flange dimensions class 150 flat face flange dimensions dimensions of flat face flanges flat face blind flange dimensions flat face flange dimensions flat face flange pdf flat face flange pressure rating

ANSI/ASME steel flanges

ANSI B16.47 Slip on flanges ANSI B16.5 lap joint flanges ANSI B16.47 steel weld neck flanges ANSI B16.47 steel blind flanges, blind cover ANSI B16.5 slip on flanges

ANSI B16.5 stainless steel blind flange ANSI B16.5 long weld neck pipe flanges, LWN flange API standard forged stainless steel thread flanges, SCRD flange ANSI B16.5 stainless steel weld neck pipe flanges

EN/PED Steel Flanges

DIN2573, DIN2576 carbon steel plate flanges DIN2527 blind flanges DIN2573, DIN2576 plate flange, backing flange,gasket EN1092-1 F304/F304L plate flange DIN2634 steel weld neck flanges

DIN2633 weld neck flanges EN1092-1 steel plate backing flanges EN1092-1 TYPE05 blind flanges EN1092-1 TYPE 11B weld neck flanges EN1092-1 type11B PN10 DN400 weld neck flange raised face

BS Steel Flanges

BS4504 code 105 steel blind flanges BS4504 code 101 steel plate flanges

BS4504 code 111 steel weld neck flanges

JIS Steel Flanges

JIS B2220 socket welding flange JIS B2220 slip on hubbed SOH flange

JIS B2220 steel Sip On plate SOP flanges JIS B2220 welding neck flanges

Flange Standard

API 6A Flange ANSI Flange ASME Flange DIN Flange EN1092-1 Flange UNI Flange

JIS/KS Flange BS4504 Flange GB Flange AWWA C207 Flange GOST Flange PSI Flange

Flat Flange Price

• stainless steel 304L flat welding flange
  US $3-8 / Piece
• forged carbon steel st37.2 flat face flanges
  US $0.1-1 / Piece
• din 2576 flat flanges
  US $0.8-1.5/ Piece
• din pn16 stainless steel 316l flange ansi b16.5 flat face flange
  US $1000-3000 / Piece
• ANSI B16.47 B flanges flat flanges cast flanges
  US $0.8-1000 / Piece
• ansi standard flange,flange ball valve,flat flange
  US $800-8000 / Piece
• weld neck flat face flange
  US $0.01-0.5 / Piece
• stainless steel flat flange 150# b16.5
  US $0.8-1000 / Piece
• laser cutting stainless steel flat flange
  US $1.86-8.65 / Piece
• flat flange with high quality
  US $10-1000 / Piece
• GOST Steel flat flange PN10
  US $5-150 / Piece
• Flat Flanges Weld On Pipes PN10 - EN1092-1.DIN2576
  US $1.0-1.0 / Piece
• stainless steel forged flat flange
  US $1-10 / Piece
• flat face flange
  US $3-199 / Piece
• ansi standard flange/flange pn16/flat flange
  US $0.5-500 / Piece
• DIN Carbon Steel A 105 NPT Threaded Flange Flat Flange
  US $0.25-14.2 / Piece
• forged carbon steel st37.2 flat face flanges
  US $0.1-1 / Piece
• slip on flat face flange
  US $1-1000 / Piece
• Flat Flange
  US $10.0-10.0 / Piece
• ANSI B16.5 flat face flange
  US $10-1000 / Piece
• Flat welding flange
  US $700-1000 / Piece
• stainless steel forged flat flange
  US $20.0-20.0 / Piece

Manufacturers And Suppliers Of Different Types Of Flanges listed Below

Forged Flanges	Blind Flanges	Slip on Flanges
Weld Neck Flanges	Lapped Joint Flanges	Threaded Flanges
Socket Weld Flanges	Long Weld Neck Flanges	Weldo / Nipo Flanges
Orifice Flanges	Reducing Flanges	Flat Flanges
Loose Flanges	RTJ Flanges	Sorf Flanges
Square Flanges	Swrf Flanges	Expander Flanges
Wnrf Flanges	Ring Type Joint Flanges	Groove & Tongue Flanges
High Hub Blinds Flanges	Spectacle Blind Flanges	Weld Neck Flanges A / B
Spades Ring Spacers Flanges	Screwed Flanges	Forging Facing Flanges
