Industrial Copper Flanges

Copper Flange Adapter 150lb

Drilling to Match ANSI B 16.5 Specifications Sizes 1-1/2" thru 8" Flanges shall be drilled to ANSI B 16.5 150 Standard powder coated with a EPDM insulator adhered to the plate steel flange protruding inside of the steel flange to prevent contact with the Copper Companion Flange Adapter. The Copper component of the flange adapter shall be manufactured to ASME B16.22 - 1995 Specifications SIZE WORKING PRESSURE (at atmospheric) MATERIAL THICKNESS 1-1/2" 450 PSI Plate Steel .63 2" 450 PSI Plate Steel .63 2-1/2" 450 PSI Plate Steel .63 3" 450 PSI Plate Steel .63 4" 450 PSI Plate Steel .709 5" 450 PSI Plate Steel .748 6" 450 PSI Plate Steel .866 8" 450 PSI Plate Steel .866 Service Temperature: -66F to +272F DIMENSIONS OF SOLDER JOINTManufatured to ASME B 16.22-95 SIZE LENGTH (K) Min FEMALE END (F) DEPTH (G) Min THICKNESS (T) Min ID (O) Min OD Cu FLANGE (L) Min Min Max 1-1/2" 1.81 1.62 1.63 1.09 .051 1.47 3.10 2" 1.85 2.12 2.33 1.34 .059 1.94 3.70 2-1/2" 2.02 2.62 2.63 1.47 .067 2.42 4.20 3" 2.35 3.12 3.13 1.66 .075 2.89 5.00 4" 2.81 4.12 4.13 2.16 .096 3.84 6.20 5" 3.87 5.12 5.13 2.66 .111 4.70 7.30 6" 4.31 6.12 6.13 3.09 .124 5.72 8.40 8" 5.50 8.12 8.13 4.00 .875 8.80 13.50

Copper Flange Adapter 300lb

Drilling to Match ANSI B 16.5 Specifications Sizes 1-1/2" thru 8" Flanges shall be drilled to ANSI B 16.5 300 Standard powder coated with a EPDM insulator adhered to the plate steel flange protruding inside of the steel flange to prevent contact with the Copper Companion Flange Adapter. The Copper component of the flange adapter shall be manufactured to ASME B16.22 - 1995. Specifications SIZE WORKING PRESSURE (at atmospheric) MATERIAL THICKNESS 1-1/2" 600 PSI Plate Steel .709 2" 600 PSI Plate Steel .787 2-1/2" 600 PSI Plate Steel .866 3" 600 PSI Plate Steel .0945 4" 600 PSI Plate Steel 1.063 5" 600 PSI Plate Steel 1.141 6" 600 PSI Plate Steel 1.181 8" 600 PSI Plate Steel 1.378 Service Temperature: -66F to +272F DIMENSIONS OF SOLDER JOINT Manufatured to ASME B 16.22-95 SIZE LENGTH (K) Min FEMALE END (F) DEPTH (G) Min THICKNESS (T) Min ID (O) Min OD Cu FLANGE (L) Min Min Max 1-1/2" 1.81 1.62 1.63 1.09 .051 1.47 3.10 2" 1.85 2.12 2.33 1.34 .059 1.94 3.70 2-1/2" 2.02 2.62 2.63 1.47 .067 2.42 4.20 3" 2.35 3.12 3.13 1.66 .075 2.89 5.00 4" 2.81 4.12 4.13 2.16 .096 3.84 6.20 5" 3.87 5.12 5.13 2.66 .111 4.70 7.30 6" 4.31 6.12 6.13 3.09 .124 5.72 8.40 8" 5.50 8.12 8.13 4.00 .875 8.80 13.50

Copper Flange Roll Grooved 150/125

Drilling to Match ANSI B 16.5 Specifications Sizes 2" thru 6" Flanges shall be drilled to ANSI B 16.5 150/125 Standard powder coated with a EPDM insulator adhered to the plate steel flange protruding inside of the steel flange to prevent contact with the Copper Companion Flange Adapter. Specifications SIZE WORKING PRESSURE (at atmospheric) MATERIAL THICKNESS 2" 450 PSI Plate Steel .63 2-1/2" 450 PSI Plate Steel .63 3" 450 PSI Plate Steel .63 4" 450 PSI Plate Steel .709 5" 450 PSI Plate Steel .748 6" 450 PSI Plate Steel .866 Service Temperature: -66F to +272F DIMENSIONS OF ROLL GROOVED COPPER COMPANION FLANGE ADAPTER GASKET SEAT GROOVE WIDTH GROOVE DIA MAX ALLOW FLARE OVERALL LENGTH THICKNESS THIN 1.0 MIN OD of FLANGE SIZE (A) +/-03 (B)=/-03 (c)=00 02 DIA (K) (T) (0) (L) 2" 0.610 0.300 2.029 2.22 2.63 0.059 1.94 3.70 2-1/2" 0.610 0.300 2.525 2.79 2.79 0.067 2.42 4.20 3" 0.610 0.300 3.025 3.12 3.12 0.075 2.89 5.00 4" 0.610 0.300 4.019 3.62 3.62 0.096 3.84 6.20 5" 0.610 0.300 5.019 3.82 3.82 0.111 4.70 7.30 6" 0.610 0.300 5.999 4.27 4.27 0.124 5.72 8.40

Copper Press Fit Flange 150lb (formerly Spigot)

Drilling to Match ANSI B 16.5 Specifications Features Sizes 2" through 4" Quick and easy Press Fit application. Save Time, Save Money. Also suitable for soldering or grooving. Suitable for all brass companion flange applications. No cracking or warping due to overheating, or cooling too rapidly. Heating and cooling time reduced or eliminated. Adjustable rotating flange, eliminating 2 holing. 100% Electrolysis Protection.* Save money on gases and solder. Copper component is 99.9% copper eliminating any lead issues. Burst pressure for 2" - 4" is 1000 PSI. Temperature range is -66F to 272F. Applications include all butterfly and flanged gate valve installations, along with pumps, boilers, chillers, backflow devices. No extra costs, such as dielectric insulators. Available in 150LB, 300LB, Specifications WORKING PRESSURE SIZE WORKING PRESSURE (at atmospheric) MATERIAL THICKNESS 2" 450 PSI Plate Steel .63 2-1/2" 450 PSI Plate Steel .63 3" 450 PSI Plate Steel .63 4" 450 PSI Plate Steel .709 SERVICE TEMPERATURE: -66F TO +272F SIZE OD CU FLANGE (A) FLARE (B) SPIG END (C) LENGTH (L) THICKNESS (T) 2" 3.75 2.31 2.125 6.00 0.07 2-1/2" 4.33 0.625 2.625 6.00 0.08 3" 5.01 0.625 3.125 6.00 0.09 4" 6.48 0.625 4.125 6.00 0.11

Types Of Industrial Copper Flanges

•	Industrial Copper Forged Flanges	•	Industrial Copper High Hub Blinds Flanges
•	Industrial Copper Blind Flanges	•	Industrial Copper Spectacle Blinds Flanges
•	Industrial Copper Reducing Flanges	•	Industrial Copper Loose Flanges
•	Industrial Copper Orifice Flanges	•	Industrial Copper RTJ Flanges
•	Industrial Copper Socket Weld Flanges	•	Industrial Copper Screwed Flanges
•	Industrial Copper Slip On Flanges	•	Industrial Copper Weld Neck Flanges
•	Industrial Copper Flat Flanges	•	Industrial Copper Flanges Facing Type & Finish
•	Industrial Copper Lapped Joint Flanges	•	Industrial Copper SORF Flanges
•	Industrial Copper SWRF Flanges	•	Industrial Copper Groove & Tongue Flanges
•	Industrial Copper Square Flanges	•	Industrial Copper Long Neck Weld Flanges
•	Industrial Copper Threaded Flanges	•	Industrial Copper Spades Ring Spacers Flanges
•	Industrial Copper Weld Neck Flanges Series A or B	•	Industrial Copper Ring Type Joint Flanges
•	Industrial Copper WNRF Flanges	•	Industrial Copper Weldo / Nipo Flanges
•	Industrial Copper Expander Flanges

Leading manufacturer of Industrial Copper Flanges

We also having stock of Industrial Copper Flanges & other Stainless Steel Flanges, Carbon Steel Flanges, Alloy Steel Flanges manufactured by :

Erne Fittings, Austria	Metal far, Italy	Lame S.R.l., Italy
BENKAN Corporation, Japan	BKL- Thai Benkan, Thailand	TecnoForge, Italy
Ulma, Spain	Mega, Italy	Melesi, Italy
Interfit, France	Raccortubi S.P.A., Italy

we are the distributor of the of these Brands. we also have the sales representative who can provide the proper information of these Brands & about Grades, material and sizes of Industrial Copper Flanges.

Our Live Stock of Industrial Copper Flanges

Click Here for Industrial Copper Weld Neck Flanges Live Stock

Click Here for Industrial Copper Forged Flanges Live Stock

Click Here for Industrial Copper Blind Flanges Live Stock

Industrial Copper Flanges Application

Industrial Copper Flanges uses in Oil and Gas Pipeline Industrial Copper Flanges uses in Chemical Industry Industrial Copper Flanges uses in Plumbing Industrial Copper Flanges uses in Oil & Gas Industry Industrial Copper Flanges uses in Water Supply Systems Industrial Copper Flanges uses in Paper & Pulp Industry

Industrial Copper Flanges uses in Power Plant Industrial Copper Flanges uses in Fabrication Industry Industrial Copper Flanges uses in General purpose applications Industrial Copper Flanges uses in Food Processing Industry Industrial Copper Flanges uses in Structural Pipe Industrial Copper Flanges uses in Heat Exchangers
