ANSI B16.5 Flanges Manufacturers in India

India's Most Experienced Manufacturers,Suppliers and Exporter of Ansi b16.5 Flanges, Ansi b16.5 Weld neck Flanges, Ansi b16.5 Slip on Flanges, Ansi b16.5 Socket weld Flanges, Ansi b16.5 Blind Flanges, Ansi b16.5 Lapped joint Flanges, Ansi b16.5 Threaded Flange, Ansi b16.5 Plate Flange in India & Uk

Ansi b16.5 Flanges

Ansi b16.5 Flanges Dimensions
ASME/ANSI B16.5 class 150
ASME/ANSI B16.5 class 300
ASME/ANSI B16.5 class 400
ASME/ANSI B16.5 class 600
ASME/ANSI B16.5 class 900
ASME/ANSI B16.5 class 1500
ASME/ANSI B16.5 class 2500
Leading manufacturer of Ansi b16.5 Flanges
Our Live Stock of Ansi b16.5 Flanges
Ansi b16.5 Flanges Application

Specifications :-

ANSI flange(American National Standards Institute) include ANSI B 16.5, ANSI B 16.47 series A SP44, Series B, ANSI 16.36 etc., this standard system include slip on flange, blind flange, welded neck flange, threaded flange, lapped joint flange (loose flange), socket welded flange, Orifice Flanges, long weld neck flange and special flange, sizes from 1/2 inch to 60 inch, class 150, class 300, class 600, class 900, class 1500, class 2500.

Type: slip on flange, blind flange, welded neck flange, threaded flange, lapped joint flange(loose flange), socket welded flange, Orifice Flanges, long welded neck flange
Material: Carbon steel: A105,SS400,SF440 RST37.2,S235JRG2,P250GH,C22.8, Stainless Steel: F304 F304L F316 F316L 316Ti, Copper Nickel etc.
Standard: ANSI,JIS,DIN,BS4504,SABS1123,EN1092-1, UNI,AS2129,GOST-12820
Size: 1/2-60 inch (DN15-DN2000)
Pressure: ANSI class 150, 300, 600, 900, 1500, 2500
Packing: No Fumigate or Fumigate Plywood/Wood Pallet or Case
Surface Treatment: Anti-rust Oil, Transparent/Yellow/Black Anti-rust Paint,Zinc,Hot dipped Galvanized.
E-catalogue: Available , please visit catalogue of flange
Usage: Oil Field, Offshore, Water System, Shipbuilding, Natural Gas, Electric Power, Pipe Projects etc.

Types Of Ansi b16.5 Flanges

•	Ansi b16.5 Forged Flanges	•	Ansi b16.5 High Hub Blinds Flanges
•	Ansi b16.5 Blind Flanges	•	Ansi b16.5 Spectacle Blinds Flanges
•	Ansi b16.5 Reducing Flanges	•	Ansi b16.5Loose Flanges
•	Ansi b16.5 Orifice Flanges	•	Ansi b16.5 RTJ Flanges
•	Ansi b16.5 Socket Weld Flanges	•	Ansi b16.5 Screwed Flanges
•	Ansi b16.5 Slip On Flanges	•	Ansi b16.5 Weld Neck Flanges
•	Ansi b16.5 Flat Flanges	•	Ansi b16.5 Flanges Facing Type & Finish
•	Ansi b16.5 Lapped Joint Flanges	•	Ansi b16.5 SORF Flanges
•	Ansi b16.5 SWRF Flanges	•	Ansi b16.5 Groove & Tongue Flanges
•	Ansi b16.5 Square Flanges	•	Ansi b16.5 Long Neck Weld Flanges
•	Ansi b16.5 Threaded Flanges	•	Ansi b16.5 Spades Ring Spacers Flanges
•	Ansi b16.5 Weld Neck Flanges Series A or B	•	Ansi b16.5 Ring Type Joint Flanges
•	Ansi b16.5 WNRF Flanges	•	Ansi b16.5 Weldo / Nipo Flanges
•	Ansi b16.5 Expander Flanges

ANSI B16.5 Flange Dimensional Sizes 1/2 to 2 1/2 inches Table Chart

The following is chart data for ANSI B16.5 Flange Dimensional Data Size table for 1/2 to 2 1/2 inches. :

DN (inch)	Dimension	ANSI B16.5 Flange Dimensional Sizes 1/2 to 2 1/2 inches Table Chart
		125 lbs 150 lbs		300 lbs		400 lbs		600 lbs		900 lbs		1500 lbs		2500 lbs
		inch	mm	inch	mm	inch	mm	inch	mm	inch	mm	inch	mm	inch		mm
1/2	A	3 1/2	88.9	3 3/4	95.2	3 3/4	95.2	3 3/4	95.2	4 3/4	121	4 3/4	121	5 1/4	133.4
	b	7/16	11.1	9/16	14.3	9/16	14.3	9/16	14.3	7/8	22.2	7/8	22.2	1 3/16	30.2
	D2	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9	1 3/8	34.9
	D1	2 3/8	60.3	2 5/8	66.7	2 5/8	66.7	2 5/8	66.7	3 1/4	82.6	3 1/4	82.6	3 1/2	88.9
	n	4	4	4	4	4	4	4	4	4	4	4	-	4	44
	d	5/8	15.9	5/8	15.9	5/8	15.9	5/8	15.9	7/8	22.2	7/8	22.2	7/8	22.2
3/4	A	3 7/8	98.4	4 5/8	117.5	4 5/8	117.5	4 5/8	117.5	5 1/8	130	5 1/8	130	5 1/2	139.7
	b	1/2	12.7	5/8	15.9	5/8	15.9	5/8	15.9	1	25.4	1	25.4	1 1/4	31.8
	D2	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9	1 11/16	42.9
	D1	2 3/4	69.8	3 1/4	82.5	3 1/4	82.5	3 1/4	82.5	3 1/2	88.9	3 1/2	88.9	3 3/4	95.2
	n	4	4	4	4	4	4	4	4	4	4	4	-	4	44
	d	5/8	15.9	3/4	19	3/4	19	3/4	19	7/8	22.2	7/8	22.2	7/8	22.2
1	A	4 1/4	108	4 7/8	123.8	4 7/8	123.8	4 7/8	123.8	5 7/8	149.2	5 7/8	149.2	6 1/4	159
	b	9/16	14.3	11/16	17.5	11/16	17.5	11/16	17.5	1 1/8	28.6	1 1/8	28.6	1 3/8	34.9
	D2	2	50.8	2	50.8	2	50.8	2	50.8	2	50.8	2	50.8	2	50.8
	D1	3 1/8	79.4	3 1/2	88.9	3 1/2	88.9	3 1/2	88.9	4	102	4	102	4 1/4	108
	n	4	4	4	4	4	4	4	4	4	4	4	4	4	4
	d	5/8	15.9	3/4	19	3/4	19	3/4	19	1	25.4	1	25.4	1	25.4
1 1/4	A	4 5/8	117.5	5 1/4	133.4	5 1/4	133.4	5 1/4	133.4	6 1/4	159	6 1/4	159	7 1/4	184.2
	b	5/8	15.9	3/4	19	13/16	20.6	13/16	20.6	1 1/8	28.6	1 1/8	28.6	1 1/2	38.1
	D2	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5	2 1/2	63.5
	D1	3 1/2	88.9	3 7/8	98.4	3 7/8	98.4	3 7/8	98.4	4 3/8	111	4 3/8	111	5 1/8	130
	n	4	4	4	4	4	4	4	4	4	4	4	4	4	4
	d	5/8	15.9	3/4	19	3/4	19	3/4	19	1	25.4	1	25.4	1 1/8	28.6
1 1/2	A	5	127	6 1/8	155.6	6 1/8	155.6	6 1/8	155.6	7	177.8	7	177.8	8	203
	b	11/16	17.5	13/16	20.6	7/8	22.2	7/8	22.2	1 1/4	31.8	1 1/4	31.8	1 3/4	44.5
	D2	2 7/8	73 98	2 7/8	73	2 7/8	73	2 7/8	73	2 7/8	73	2 7/8	73	2 7/8	73
	D1	3 7/8	4	4 1/2	114	4 1/2	114	4 1/2	114	4 7/8	124	4 7/8	124	5 3/4	146
	n	4	4	4	4	4	4	4	4	4	4	4	4	4	4
	d	5/8	. 15.9	7/8	22.2	7/8	22.2	7/8	22.2	1 1/8	28.6	1 1/8	28.6	1 1/4	31.8
2	A	6	152.4	6 1/2	165.1	6 1/2	165.1	6 1/2	165.1	8 1/2	215.9	8 1/2	215.9	9 1/4	234.9
	b	3/4	19	7/8	22.2	1	25.4	1	25.4	1 1/2	38.1	1 1/2	38.1	2	50.8
	D2	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1	3 5/8	92.1
	D1	4 3/4	121	5	127	5	127	5	127	6 1/2	165.1	6 1/2	165.1	6 3/4	171
	n	4	4	8	8	8	8	8	8	8	8	8	8	8	8
	d	3/4	19	3/4	19	3/4	19	3/4	19	1	25.4	1	25.4	1 1/8	28.6
2 1/2	A	7	177.8	7 1/2	190.5	7 1/2	190.5	7 1/2	190.5	9 5/8	244	9 5/8	244	10 1/2	266.7
	b	7/8	22.2	1	25.4	1 1/8	28.6	1 1/8	28.6	1 5/8	41.3	1 5/8	41.3	2 1/4	57.2
	D2	4 1/8	104.8	4 1/8	104.8	4 1/8	104.8	4 1/8	104.8	4 1/8	105	4 1/8	105	4 1/8	105
	D1	5 1/2	139.7	5 7/8	149.2	5 7/8	149.2	5 7/8	149.2	7 1/2	190.5	7 1/2	190.5	7 3/4	197
	n	4	4	8	8	8	8	8	8	8	8	8	8	8	8
	d	3/4	19	7/8	22.2	7/8	22.2	7/8	22.2	1 1/8	28.6	1 1/8	28.6	1 1/4	31.8

Flange dimensions for pipes ranging 1/2″ to 24″ – in classes ranging 150 to 2500.

ASME/ANSI B16.5 class 150

Nominal Pipe Size NPS (inches)	Class 150
Nominal Pipe Size NPS (inches)	Diameter of Flange (inches)	No. of Bolts	Diameter of Bolts (inches)	Diameter of Bolt Holes (inches)	Bolt Circle (inches)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

ASME/ANSI B16.5 class 300

Nominal Pipe Size NPS (inches)	Class 300
Nominal Pipe Size NPS (inches)	Diameter of Flange (inches)	No. of Bolts	Diameter of Bolts (inches)	Diameter of Bolt Holes (inches)	Bolt Circle (inches)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-3/4	4	1/2	0.62	2-5/8
3/4	4-5/8	4	5/8	0.75	3-1/4
1	4-7/8	4	5/8	0.75	3-1/2
1-1/4	5-1/4	4	5/8	0.75	3-7/8
1-1/2	6-1/8	4	3/4	0.88	4-1/2
2	6-1/2	8	5/8	0.75	5
2-1/2	7-1/2	8	3/4	0.88	5-7/8
3	8-1/4	8	3/4	0.88	6-5/8
3-1/2	9	8	3/4	0.88	7-1/4
4	10	8	3/4	0.88	7-7/8
5	11	8	3/4	0.88	9-1/4
6	12-1/2	12	3/4	0.88	10-5/8
8	15	12	7/8	1	13
10	17-1/2	16	1	1.12	15-1/4
12	20-1/2	16	1-1/8	1.25	17-3/4
14	23	20	1-1/8	1.25	20-1/4
16	25-1/2	20	1-1/4	1.38	22-1/2
18	28	24	1-1/4	1.38	24-3/4
20	30-1/2	24	1-1/4	1.38	27
24	36	24	1-1/2	1.62	32

ASME/ANSI B16.5 class 400

Nominal Pipe Size NPS (inches)	Class 400
Nominal Pipe Size NPS (inches)	Diameter of Flange (inches)	No. of Bolts	Diameter of Bolts (inches)	Diameter of Bolt Holes (inches)	Bolt Circle (inches)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-3/4	4	1/2	0.62	2-5/8
3/4	4-5/8	4	5/8	0.75	3-1/4
1	4-7/8	4	5/8	0.75	3-1/2
1-1/4	5-1/4	4	5/8	0.75	3-7/8
1-1/2	6-1/8	4	3/4	0.88	4-1/2
2	6-1/2	8	5/8	0.75	5
2-1/2	7-1/2	8	3/4	0.88	5-7/8
3	8-1/4	8	3/4	0.88	6-5/8
3-1/2	9	8	7/8	1	7-1/4
4	10	8	7/8	1	7-7/8
5	11	8	7/8	1	9-1/4
6	12-1/2	12	7/8	1	10-5/8
8	15	12	1	1.12	13
10	17-1/2	16	1-1/8	1.25	15-1/4
12	20-1/2	16	1-1/4	1.38	17-3/4
14	23	20	1-1/4	1.38	20-1/4
16	25-1/2	20	1-3/8	1.5	22-1/2
18	28	24	1-3/8	1.5	24-3/4
20	30-1/2	24	1-1/2	1.62	27
24	36	24	1-3/4	1.88	32

ASME/ANSI B16.5 class 600

Nominal Pipe Size NPS (inches)	Class 600
Nominal Pipe Size NPS (inches)	Diameter of Flange (inches)	No. of Bolts	Diameter of Bolts (inches)	Diameter of Bolt Holes (inches)	Bolt Circle (inches)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-3/4	4	1/2	0.62	2-5/8
3/4	4-5/8	4	5/8	0.75	3-1/4
1	4-7/8	4	5/8	0.75	3-1/2
1-1/4	5-1/4	4	5/8	0.75	3-7/8
1-1/2	6-1/8	4	3/4	0.88	4-1/2
2	6-1/2	8	5/8	0.75	5
2-1/2	7-1/2	8	3/4	0.88	5-7/8
3	8-1/4	8	3/4	0.88	6-5/8
3-1/2	9	8	7/8	1	7-1/4
4	10-3/4	8	7/8	1	8-1/2
5	13	8	1	1.12	10-1/2
6	14	12	1	1.12	11-1/2
8	16-1/2	12	1-1/8	1.25	13-3/4
10	20	16	1-1/4	1.38	17
12	22	20	1-1/4	1.38	19-1/4
14	23-3/4	20	1-3/8	1.5	20-3/4
16	27	20	1-1/2	1.62	23-3/4
18	29-1/4	20	1-5/8	1.75	25-3/4
20	32	24	1-5/8	1.75	28-1/2
24	37	24	1-7/8	2	33

ASME/ANSI B16.5 class 900

Nominal Pipe Size NPS (inches)	Class 900
Nominal Pipe Size NPS (inches)	Diameter of Flange (inches)	No. of Bolts	Diameter of Bolts (inches)	Diameter of Bolt Holes (inches)	Bolt Circle (inches)
1/2	4-3/4	4	3/4	0.88	3-1/4
3/4	5-1/8	4	3/4	0.88	3-1/2
1	5-7/8	4	7/8	1	4
1-1/4	6-1/4	4	7/8	1	4-3/8
1-1/2	7	4	1	1.12	4-7/8
2	8-1/2	8	7/8	1	6-1/2
2-1/2	9-5/8	8	1	1.12	7-1/2
3	9-1/2	8	7/8	1	7-1/2
4	11-1/2	8	1-1/8	1.25	9-1/4
5	13-3/4	8	1-1/4	1.38	11
6	15	12	1-1/8	1.25	12-1/2
8	18-1/2	12	1-3/8	1.5	15-1/2
10	21-1/2	16	1-3/8	1.5	18-1/2
12	24	20	1-3/8	1.5	21
14	25-1/4	20	1-1/2	1.62	22
16	27-3/4	20	1-5/8	1.75	24-1/2
18	31	20	1-7/8	2	27
20	33-3/4	20	2	2.12	29-1/2
24	41	20	2-1/2	2.62	35-1/2

ASME/ANSI B16.5 class 1500

Nominal Pipe Size NPS (inches)	Class 1500
Nominal Pipe Size NPS (inches)	Diameter of Flange (inches)	No. of Bolts	Diameter of Bolts (inches)	Diameter of Bolt Holes (inches)	Bolt Circle (inches)
1/2	4-3/4	4	3/4	0.88	3-1/4
3/4	5-1/8	4	3/4	0.88	3-1/2
1	5-7/8	4	7/8	1	4
1-1/4	6-1/4	4	7/8	1	4-3/8
1-1/2	7	4	1	1.12	4-7/8
2	8-1/2	8	7/8	1	6-1/2
2-1/2	9-5/8	8	1	1.12	7-1/2
3	10-1/2	8	1-1/8	1.25	8
4	12-1/4	8	1-1/4	1.38	9-1/2
5	14-3/4	8	1-1/2	1.62	11-1/2
6	15-1/2	12	1-3/8	1.5	12-1/2
8	19	12	1-5/8	1.75	15-1/2
10	23	12	1-7/8	2	19
12	26-1/2	16	2	2.12	22-1/2
14	29-1/2	16	2-1/4	2.38	25
16	32-1/2	16	2-1/2	2.62	27-3/4
18	36	16	2-3/4	2.88	30-1/2
20	38-3/4	16	3	3.12	32-3/4
24	46	16	3-1/2	3.62	39

ASME/ANSI B16.5 class 2500

Nominal Pipe Size NPS (inches)	Class 2500
Nominal Pipe Size NPS (inches)	Diameter of Flange (inches)	No. of Bolts	Diameter of Bolts (inches)	Diameter of Bolt Holes (inches)	Bolt Circle (inches)
1/2	5-1/4	4	3/4	0.88	3-1/2
3/4	5-1/2	4	3/4	0.88	3-3/4
1	6-1/4	4	7/8	1	4-1/4
1-1/4	7-1/4	4	1	1.12	5-1/8
1-1/2	8	4	1-1/8	1.25	5-3/4
2	9-1/4	8	1	1.12	6-3/4
2-1/2	10-1/2	8	1-1/8	1.25	7-3/4
3	12	8	1-1/4	1.38	9
4	14	8	1-1/2	1.62	10-3/4
5	16-1/2	8	1-3/4	1.88	12-3/4
6	19	8	2	2.12	14-1/2
8	21-3/4	12	2	2.12	17-1/4
10	26-1/2	12	2-1/2	2.62	21-1/4
12	30	12	2-3/4	2.88	24-3/8

15mm (1/2") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS4087 Flanges	PN14 Flanges	95	67	4	M12	14
AS 2129 Flange	Table C Flanges	95	67	4	13	14
	Table D Flanges	95	67	4	13	14
	Table E Flanges	95	67	4	13	14
	Table F Flanges	95	67	4	13	14
	Table H Flanges	114	83	4	16	17
	Table J Flanges	114	83	4	16	17
ANSI B16.5 Flanges	ANSI 150 Flanges	89	60	4	13	16
	ANSI 300 Flanges	95	67	4	13	16
	ANSI 600 Flanges	95	67	4	13	16
	ANSI 900 Flanges	121	83	4	19	22
	ANSI 1500 Flanges	121	83	4	19	22
ISO 7005 (DIN) Flange	PN6 Flanges	80	55	4	M10	11
	PN10 Flanges	95	65	4	M12	14
	PN16 Flanges	95	65	4	M12	14
	PN20 Flanges	90	60.5	4	M14	16
	PN25 Flanges	95	65	4	M12	14
	PN40 Flanges	95	65	4	M12	14

20mm (3/4") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS4087 Flanges	PN14 Flanges	100	73	4	M12	14
AS 2129 Flange	Table C Flange	100	73	4	13	14
	Table D Flange	100	73	4	13	14
	Table E Flange	100	73	4	13	14
	Table F Flange	100	73	4	13	14
	Table H Flange	115	83	4	16	18
	Table J Flange	115	83	4	16	18
ANSI B16.5 Flanges	ANSI 150 Flange	98	70	4	13	16
	ANSI 300 Flange	117	83	4	16	19
	ANSI 600 Flange	117	83	4	16	19
	ANSI 900 Flange	130	89	4	19	22
	ANSI 1500 Flange	130	89	4	19	22
ISO 7005 (DIN) Flange	PN6 Flange	90	65	4	M10	11
	PN10 Flange	105	75	4	M12	14
	PN16 Flange	105	75	4	M12	14
	PN20 Flange	100	70	4	M14	16
	PN25 Flange	105	75	4	M12	14
	PN40 Flange	105	75	4	M12	14

25mm (1") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS4087 Flanges	PN14 Flanges	115	83	4	M12	14
AS 2129 Flange	Table C Flanges	115	83	4	13	14
	Table D Flanges	115	83	4	13	14
	Table E Flanges	115	83	4	13	14
	Table F Flanges	120	87	4	16	18
	Table H Flanges	120	87	4	16	18
	Table J Flanges	120	87	4	16	18
ANSI B16.5 Flanges	ANSI 150 Flanges	110	79	4	13	16
	ANSI 300 Flanges	125	89	4	16	19
	ANSI 600 Flanges	125	89	4	16	19
	ANSI 900 Flanges		102	4	22	25
	ANSI 1500 Flanges		102	4	22	25
ISO 7005 (DIN) Flange	PN6 Flanges	100	78	4	M10	11
	PN10 Flanges	115	85	4	M12	14
	PN16 Flanges	115	85	4	M12	14
	PN20 Flanges	110	79.5	4	M14	16
	PN25 Flanges	115	85	4	M12	14
	PN40 Flanges	115	85	4	M12	14

32mm (1 1/4") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS4087 Flanges	PN14 Flanges	120	87	4	M12	14
AS 2129 Flange	Table C Flange	120	87	4	13	14
	Table D Flange	120	87	4	13	14
	Table E Flange	120	87	4	13	14
	Table F Flange	135	98	4	16	18
	Table H Flange	135	98	4	16	18
	Table J Flange	135	98	4	16	18
ANSI B16.5 Flanges	ANSI 150 Flange	117	89	4	13	16
	ANSI 300 Flange	133	98	4	16	19
	ANSI 600 Flange	133	98	4	16	19
	ANSI 900 Flange	159	111	4	22	25
	ANSI 1500 Flange	159	111	4	22	25
ISO 7005 (DIN) Flange	PN6 Flange	120	90	4	M12	14
	PN10 Flange	140	100	4	M16	18
	PN16 Flange	140	100	4	M16	18
	PN20 Flange	120	89	4	M14	16
	PN25 Flange	140	100	4	M16	18
	PN40 Flange	140	100	4	M16	18

40mm (1 1/2") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS4087 Flanges	PN14 Flanges	135	98	4	M12	14
AS 2129 Flange	Table C Flanges	135	98	4	13	14
	Table D Flanges	135	98	4	13	14
	Table E Flanges	135	98	4	13	14
	Table F Flanges	140	105	4	16	18
	Table H Flanges	140	105	4	16	18
	Table J Flanges	140	105	4	16	18
ANSI B16.5 Flanges	ANSI 150 Flanges	127	98	4	13	16
	ANSI 300 Flanges	156	114	4	19	22
	ANSI 600 Flanges	156	114	4	19	22
	ANSI 900 Flanges	178	124	4	25	29
	ANSI 1500 Flanges	178	124	4	25	29
ISO 7005 (DIN) Flange	PN6 Flanges	130	100	4	M12	14
	PN10 Flanges	150	110	4	M16	18
	PN16 Flanges	150	110	4	M16	18
	PN20 Flanges	130	98.5	4	M14	16
	PN25 Flanges	150	110	4	M16	18
	PN40 Flanges	150	110	4	M16	18

50mm (2") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087 Flange	PN14 Flange	150	114	4	M16	18
	PN16 Flange	150	114	4	M16	18
	PN21 Flange	165	127	4	M16	18
	PN35 Flange	165	127	4	M16	18
AS 2129 Flange	Table C Flange	150	114	4	16	18
	Table D Flange	150	114	4	16	18
	Table E Flange	150	114	4	16	18
	Table F Flange	165	127	4	16	18
	Table H Flange	165	127	4	16	18
	Table J Flange	165	127	4	19	22
ANSI B16.5 Flange	ANSI 150 Flange	152	121	4	16	19
	ANSI 300	165	127	8	16	19
	ANSI 600	165	127	8	16	19
	ANSI 900	216	165	8	22	25
	ANSI 1500	216	165	8	22	25
ISO 7005 (DIN) Flange	PN6 Flange	140	110	4	M12	14
	PN10 Flange	165	125	4	M16	18
	PN16 Flange	165	125	4	M16	18
	PN20 Flange	150*	120.5	4	M16	18
	PN25 Flange	165	125	4	M16	18
	PN40 Flange	165	125	4	M16	18

*When made from cast or ductile iron the OD is 155mm.

65mm (2 1/2") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087 Flanges	PN14 Flanges	165	127	4	M16	18
	PN16 Flanges	165	127	4	M16	18
	PN21 Flanges	185	146	8	M16	18
	PN35 Flanges	185	146	8	M16	18
AS 2129 Flanges	Table C Flanges	165	127	4	16	18
	Table D Flanges	165	127	4	16	18
	Table E Flanges	165	127	4	16	18
	Table F Flanges	185	146	8	16	18
	Table H Flanges	185	146	8	16	18
	Table J Flanges	185	146	8	19	22
ANSI B16.5 Flanges	ANSI 150 Flanges	178	140	4	16	19
	ANSI 300 Flanges	191	149	8	19	22
	ANSI 600 Flanges	191	149	8	19	22
	ANSI 900 Flanges	244	191	8	22	25
	ANSI 1500 Flanges	244	191	8	25	29
ISO 7005 (DIN) Flanges	PN6 Flanges	160	130	4	M12	14
	PN10 Flanges	185	145	4	M16	18
	PN16 Flanges	185	145	4	M16	18
	PN20 Flanges	180	139.5	4	M16	18
	PN25 Flanges	185	145	8	M16	18
	PN40 Flanges	185	145	8	M16	18

80mm (3") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087 Flange	PN14 Flange	185	146	4	M16	18
	PN16 Flange	185	146	4	M16	18
	PN21 Flange	205	165	8	M16	18
	PN35 Flange	205	165	8	M16	18
AS 2129 Flange	Table C Flange	185	146	4	16	18
	Table D Flange	185	146	4	16	18
	Table E Flange	165	146	4	16	18
	Table F Flange	205	165	8	16	18
	Table H Flange	205	165	8	16	18
	Table J Flange	205	165	8	19	22
ANSI B16.5 Flange	ANSI 150 Flange	191	152	4	16	19
	ANSI 300 Flange	210	168	8	19	22
	ANSI 600 Flange	210	168	8	19	22
	ANSI 900 Flange	241	192	8	22	25
	ANSI 1500 Flange	267	203	8	29	32
ISO 7005 (DIN) Flange	PN6 Flange	190	150	4	M16	18
	PN10 Flange	200	160	8	M16	18
	PN16 Flange	200	160	8	M16	18
	PN20 Flange	190	152.5	4	M16	18
	PN25 Flange	200	160	8	M16	18
	PN40 Flange	185	160	8	M16	18

100mm (4") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087 Flanges	PN14 Flanges	215	178	4	M16	18
	PN16 Flanges	215	178	4	M16	18
	PN21 Flanges	230	191	8	M16	18
	PN35 Flanges	230	191	8	M16	18
AS 2129 Flanges	Table C Flanges	215	178	4	16	18
	Table D Flanges	215	178	4	16	18
	Table E Flanges	215	178	8	16	18
	Table F Flanges	230	191	8	16	18
	Table H Flanges	230	191	8	16	18
	Table J Flanges	230	191	8	19	22
ANSI B16.5 Flanges	ANSI 150 Flanges	229	191	8	16	19
	ANSI 300 Flanges	254	200	8	19	22
	ANSI 600 Flanges	273	216	8	22	25
	ANSI 900 Flanges	292	235	8	29	32
	ANSI 1500 Flanges	311	241	8	32	35
ISO 7005 (DIN) Flanges	PN6 Flanges	210	170	4	M16	18
	PN10 Flanges	220	180	8	M16	24
	PN16 Flanges	220	180	8	M16	18
	PN20 Flanges	230	190.5	8	M16	18
	PN25 Flanges	235	190	8	M20	22
	PN40 Flanges	235	190	8	M20	22

125mm (5") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087 Flanges	PN14 Flanges	280	235	8	M16	18
	PN16 Flanges	-	-	-	-	-
	PN21 Flanges	-	-	-	-	-
	PN35 Flanges	-	-	-	-	-
AS 2129 Flanges	Table C Flanges	255	210	8	16	18
	Table D Flanges	255	210	8	16	18
	Table E Flanges	255	210	8	16	18
	Table F Flanges	280	235	8	19	22
	Table H Flanges	280	235	8	19	22
	Table J Flanges	280	235	8	22	26
ANSI B16.5 Flanges	ANSI 150 Flanges	254	216	8	19	22
	ANSI 300 Flanges	279	235	8	19	22
	ANSI 600 Flanges	330	267	8	25	29
	ANSI 900 Flanges	349	279	8	32	35
	ANSI 1500 Flanges	375	292	8	38	41
ISO 7005 (DIN) Flanges	PN6 Flanges	240	200	8	M16	18
	PN10 Flanges	250	210	8	M16	18
	PN16 Flanges	250	210	8	M16	18
	PN20 Flanges	255	216	8	M20	22
	PN25 Flanges	270	220	8	M24	26
	PN40 Flanges	270	220	8	M24	26

150mm (6") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087	PN14 Flanges	280	235	8	M16	18
	PN16 Flanges	280	235	8	M16	18
	PN21 Flanges	305	260	12	M20	22
	PN35 Flanges	305	260	12	M20	22
AS 2129	Table C Flanges	280	235	8	16	18
	Table D Flanges	280	235	8	16	18
	Table E Flanges	280	235	8	19	22
	Table F Flanges	305	260	12	19	22
	Table H Flanges	305	260	12	19	22
	Table J Flanges	305	260	12	22	26
ANSI B16.5	ANSI 150 Flanges	279	241	8	19	22
	ANSI 300 Flanges	318	270	12	19	22
	ANSI 600 Flanges	356	292	12	25	29
	ANSI 900 Flanges	381	318	12	29	32
	ANSI 1500 Flanges	394	318	12	35	38
ISO 7005 (DIN)	PN6 Flanges	265	225	8	M16	18
	PN10 Flanges	285	240	8	M20	22
	PN16 Flanges	285	240	8	M20	22
	PN20 Flanges	280	241.5	8	M20	22
	PN25 Flanges	300	250	8	M24	26
	PN40 Flanges	300	250	8	M24	26

200mm (8")

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087	PN14 Flange	335	292	8	M16	18
	PN16 Flange	335	292	8	M16	18
	PN21 Flange	370	324	12	M20	22
	PN35 Flange	370	324	12	M20	22
AS 2129	Table C Flange	335	292	8	16	18
	Table D Flange	335	292	8	16	18
	Table E Flange	335	292	8	19	22
	Table F Flange	370	324	12	19	22
	Table H Flange	370	324	12	19	22
	Table J Flange	370	324	12	22	26
ANSI B16.5	ANSI 150 Flange	343	298	8	19	22
	ANSI 300 Flange	381	330	12	19	22
	ANSI 600 Flange	419	349	12	29	32
	ANSI 900 Flange	470	394	12	35	38
	ANSI 1500 Flange	483	394	12	41	44
ISO 7005 (DIN)	PN6 Flange	320	280	8	M16	18
	PN10 Flange	340	295	8	M20	22
	PN16 Flange	340	295	12	M20	22
	PN20 Flange	345	298.5	8	M20	22
	PN25 Flange	360	310	12	M24	26
	PN40 Flange	375	320	12	M27	30

250mm (10") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087	PN14 Flange	405	356	8	M20	22
	PN16 Flange	405	356	8	M20	22
	PN21 Flange	430	381	12	M24	26
	PN35 Flange	430	381	12	M24	26
AS 2129	Table C Flange	405	356	8	19	22
	Table D Flange	405	356	8	19	22
	Table E Flange	405	356	12	19	22
	Table F Flange	430	381	12	22	26
	Table H Flange	430	381	12	22	26
	Table J Flange	430	381	12	25	30
ANSI B16.5	ANSI 150 Flange	406	362	12	22	25
	ANSI 300 Flange	445	387	16	25	29
	ANSI 600 Flange	508	432	16	32	35
	ANSI 900 Flange	546	470	16	35	38
	ANSI 1500 Flange	584	483	12	41	51
ISO 7005 (DIN)	PN6 Flange	375	335	12	M16	18
	PN10 Flange	395	350	12	M20	22
	PN16 Flange	405	355	12	M24	26
	PN20 Flange	405	362	12	M24	26
	PN25 Flange	425	370	12	M27	30
	PN40 Flange	450	385	12	M30	33

300mm (12") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087	PN14 Flanges	455	406	12	M20	22
	PN16 Flanges	455	406	12	M20	22
	PN21 Flanges	490	438	16	M24	26
	PN35 Flanges	490	438	16	M24	26
AS 2129	Table C Flanges	455	406	12	19	22
	Table D Flanges	455	406	12	19	22
	Table E Flanges	455	406	12	22	26
	Table F Flanges	490	438	16	22	26
	Table H Flanges	490	438	16	22	26
	Table J Flanges	490	438	16	25	30
ANSI B16.5	ANSI 150 Flanges	483	432	12	22	25
	ANSI 300 Flanges	521	451	16	29	32
	ANSI 600 Flanges	559	489	20	32	35
	ANSI 900 Flanges	610	533	20	35	38
	ANSI 1500 Flanges	673	571	16	51	54
ISO 7005 (DIN)	PN6 Flanges	440	395	12	M20	22
	PN10 Flanges	445	400	12	M20	22
	PN16 Flanges	460	410	12	M24	26
	PN20 Flanges	485	432	12	M24	26
	PN25 Flanges	485	430	16	M27	30
	PN40 Flanges	515	450	16	M30	33

350mm (14") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087	PN14 Flanges	525	470	12	M24	26
	PN16 Flanges	525	470	12	M24	26
	PN21 Flanges	550	495	16	M27	30
	PN35 Flanges	550	495	16	M27	30
AS 2129	Table C Flanges	525	470	12	22	26
	Table D Flanges	525	470	12	22	26
	Table E Flanges	525	470	12	22	26
	Table F Flanges	550	495	16	25	30
	Table H Flanges	550	495	16	25	30
	Table J Flanges	550	495	16	29	32
ANSI B16.5	ANSI 150 Flanges	533	476	12	25	29
	ANSI 300 Flanges	584	514	20	29	32
	ANSI 600 Flanges	603	527	20	38	41
	ANSI 900 Flanges	641	559	20	38	41
	ANSI 1500 Flanges	749	635	16	57	60
ISO 7005 (DIN)	PN6 Flanges	490	445	12	M20	22
	PN10 Flanges	505	460	16	M20	22
	PN16 Flanges	520	470	16	M24	26
	PN20 Flanges	535	476	12	M27	35
	PN25 Flanges	555	490	16	M30	33
	PN40 Flanges	580	510	16	M33	36

400mm (16") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087	PN14 Flange	580	521	12	M24	26
	PN16 Flange	580	521	12	M24	26
	PN21 Flange	610	552	20	M27	30
	PN35 Flange	610	552	20	M27	30
AS 2129	Table C Flange	580	521	12	22	26
	Table D Flange	580	521	12	22	26
	Table E Flange	580	521	12	22	26
	Table F Flange	610	552	20	25	30
	Table H Flange	610	552	20	25	30
	Table J Flange	610	552	20	29	33
ANSI B16.5	ANSI 150 Flange	597	540	16	25	29
	ANSI 300 Flange	648	572	20	32	35
	ANSI 600 Flange	686	603	20	38	41
	ANSI 900 Flange	705	616	20	41	44
	ANSI 1500 Flange	826	705	16	64	67
ISO 7005 (DIN)	PN6 Flange	540	495	16	M20	22
	PN10 Flange	565	515	16	M24	26
	PN16 Flange	580	525	16	M27	30
	PN20 Flange	600	540	16	M27	29.5
	PN25 Flange	620	550	16	M33	36
	PN40 Flange	660	585	16	M36	39

450mm (18") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087	PN14 Flange	640	584	12	M24	26
	PN16 Flange	640	584	12	M24	26
	PN21 Flange	675	610	20	M30	33
	PN35 Flange	675	510	20	M30	33
AS 2129	Table C Flange	640	584	12	22	26
	Table D Flange	640	584	12	22	26
	Table E Flange	640	584	16	22	26
	Table F Flange	675	610	20	29	33
	Table H Flange	675	610	20	29	33
	Table J Flange	675	610	20	32	35
ANSI B16.5	ANSI 150 Flange	635	578	16	29	32
	ANSI 300 Flange	711	629	24	32	35
	ANSI 600 Flange	743	654	20	41	44
	ANSI 900 Flange	787	686	20	48	51
	ANSI 1500 Flange	914	775	16	70	73
ISO 7005 (DIN)	PN6 Flange	595	550	16	M20	22
	PN10 Flange	615	565	20	M24	26
	PN16 Flange	640	585	20	M27	30
	PN20 Flange	635	578	16	M30	32.5
	PN25 Flange	-	-	-	-	-
	PN40 Flange	-	-	-	-	-

500mm (20") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087	PN14 Flange	705	641	16	M24	26
	PN16 Flange	705	641	16	M24	26
	PN21 Flange	735	673	24	M30	33
	PN35 Flange	735	673	24	M30	33
AS 2129	Table C Flange	705	641	16	22	26
	Table D Flange	705	641	16	22	26
	Table E Flange	705	641	16	22	26
	Table F Flange	735	673	24	29	33
	Table H Flange	735	673	24	29	33
	Table J Flange	735	673	24	32	36
ANSI B16.5	ANSI 150 Flange	699	635	20	29	32
	ANSI 300 Flange	775	686	24	32	35
	ANSI 600 Flange	813	724	24	41	44
	ANSI 900 Flange	857	749	20	51	54
	ANSI 1500 Flange	984	832	16	76	79
ISO 7005 (DIN)	PN6 Flange	645	600	20	M20	22
	PN10 Flange	670	620	20	M24	26
	PN16 Flange	715	650	20	M30	33
	PN20 Flange	700	635	20	M30	32.5
	PN25 Flange	-	-	-	-	-
	PN40 Flange	-	-	-	-	-

600mm (24") Flanges

Standard	Class	Diameter	Bolt Circle Diameter	Number of Bolts	Bolt Size	Diameter of Bolt Hole
AS 4087	PN14 Flanges	825	756	16	M27	30
	PN16 Flanges	825	756	16	M27	30
	PN21 Flanges	850	781	24	M33	36
	PN35 Flanges	750	781	24	M33	36
AS 2129	Table C Flanges	825	756	16	25	30
	Table D Flanges	825	756	16	25	30
	Table E Flanges	825	756	16	29	33
	Table F Flanges	850	781	24	32	36
	Table H Flanges	850	781	24	32	36
	Table J Flanges	850	781	24	35	39
ANSI B16.5	ANSI 150 Flanges	813	749	20	32	35
	ANSI 300 Flanges	914	813	24	38	41
	ANSI 600 Flanges	940	838	24	48	51
	ANSI 900 Flanges	1041	902	20	64	67
	ANSI 1500 Flanges	1168	991	16	89	92
ISO 7005 (DIN)	PN6 Flanges	755	705	20	M24	26
	PN10 Flanges	780	725	20	M27	30
	PN16 Flanges	840	770	20	M33	36
	PN20 Flanges	815	749.5	20	M33	36
	PN25 Flanges	-	-	-	-	-
	PN40 Flanges	-	-	-	-	-

Leading manufacturer of Ansi b16.5 Flanges

We also having stock of Forged Flanges & other Stainless Steel Flanges, Carbon Steel Flanges, Alloy Steel Flanges manufactured by :

Erne Fittings, Austria	Metal far, Italy	Lame S.R.l., Italy
BENKAN Corporation, Japan	BKL- Thai Benkan, Thailand	TecnoForge, Italy
Ulma, Spain	Mega, Italy	Melesi, Italy
Interfit, France	Raccortubi S.P.A., Italy

we are the distributor of the of these Brands. we also have the sales representative who can provide the proper information of these Brands & about Grades, material and sizes of Ansi b16.5 Flanges.

Our Live Stock of Ansi b16.5 Flanges

Click Here for Ansi b16.5 Weld Neck Flanges Live Stock

Click Here for Ansi b16.5 Forged Flanges Live Stock

Click Here for Ansi b16.5 Blind Flanges Live Stock

Ansi b16.5 Flanges Application

Ansi b16.5 Flanges uses in Oil and Gas Pipeline
Ansi b16.5 Flanges uses in Chemical Industry
Ansi b16.5 Flanges uses in Plumbing
Ansi b16.5 Flanges uses in Oil & Gas Industry
Ansi b16.5 Flanges uses in Water Supply Systems
Ansi b16.5 Flanges uses in Paper & Pulp Industry

Ansi b16.5 Flanges uses in Power Plant
Ansi b16.5 Flanges uses in Fabrication Industry
Ansi b16.5 Flanges uses in General purpose applications
Ansi b16.5 Flanges uses in Food Processing Industry
Ansi b16.5 Flanges uses in Structural Pipe
Ansi b16.5 Flanges uses in Heat Exchangers

Flanges :: Flange Standard, Fitting Standard, Pipe Standard, Valve Standard
ANSI Flange	DIN Flange	EN Flange
ASME Flange	JIS/KS Flange	GB Flange
GOST Flange	BS Flange	UNI / Api Flange
Flanges ::
Blind Flanges	Reducing Threaded Flanges	Lap Joint Flanges
Flange Gaskets	Threaded Flanges	Socketweld Flanges
Flanges Bolts	Ring Flange	Spectacle Blind Flanges
Weld Neck Flanges	Orifice Flange	Slip-On-Flanges
High Hub Blinds Flanges

Manufacturers And Suppliers Of Different Types Of Flanges listed Below


Forged Flanges	Blind Flanges	Slip on Flanges

Weld Neck Flanges	Lapped Joint Flanges	Threaded Flanges

Socket Weld Flanges	Long Weld Neck Flanges	Weldo / Nipo Flanges

Orifice Flanges	Reducing Flanges	Flat Flanges

Loose Flanges	RTJ Flanges	Sorf Flanges

Square Flanges	Swrf Flanges	Expander Flanges

Wnrf Flanges	Ring Type Joint Flanges	Groove & Tongue Flanges

High Hub Blinds Flanges	Spectacle Blind Flanges	Weld Neck Flanges A / B

Spades Ring Spacers Flanges	Screwed Flanges	Forging Facing Flanges

Cities We Deliver To

Riyadh, Faridabad, Courbevoie, Kolkata, Rajkot, Howrah, Atyrau, Petaling Jaya, Ankara, Ho Chi Minh City, Kanpur, Istanbul, Geoje-si, La Victoria, Ahmedabad, Los Angeles, Montreal, New Delhi, Granada, Jeddah, Aberdeen, Calgary, Nashik, London, Chandigarh, Hyderabad, Chiyoda, Milan, Gimhae-si, Mumbai, Kuala Lumpur, Muscat, Ranchi, Abu Dhabi, Jakarta, Ernakulam, Tehran, Vung Tau, Kuwait City, Surat, Sydney, Houston, Edmonton, Ludhiana, Pune, Port-of-Spain, Ulsan, Caracas, Coimbatore, Mexico City, Hanoi, Al Khobar, Pimpri-Chinchwad, Bangkok, Secunderabad, Vadodara, Jaipur, Perth, Chennai, Cairo, Karachi, New York, Gurgaon, Melbourne, Manama, Busan, Rio de Janeiro, Colombo, Bengaluru, Madrid, Indore, Toronto, Ahvaz, Dubai, Thiruvananthapuram, Bhopal, Brisbane, Nagpur, Sharjah, Al Jubail, Thane, Dammam, Singapore, Santiago, Haryana, Doha, Moscow, Lagos, Jamshedpur, Baroda, Visakhapatnam, Dallas, Lahore, Hong Kong, Seoul, Noida, Bogota, Algiers, Navi Mumbai

Countries We Deliver To

Indonesia, Hong Kong, Kenya, Trinidad & Tobago,Tunisia, Kuwait, Russia, Norway, Mongolia, Croatia, Tibet, Nigeria, Nepal, Czech Republic, Portugal, Spain, Turkey, Finland, Lebanon, Azerbaijan, France, Japan, South Korea, Libya, Bolivia, Iraq, United Arab Emirates, Germany, Saudi Arabia, Jordan, Zimbabwe, Netherlands, Bhutan, United States, Morocco, Switzerland, Austria, Puerto Rico, Lithuania, Sweden, Poland, Serbia, Romania, Denmark, Bulgaria, South Africa, Iran, China, Qatar, Nigeria, Bangladesh, Gambia, Slovakia, New Zealand, Peru, Canada, Yemen, Ireland, Sri Lanka, Philippines, Iran, Costa Rica, Ecuador, Mexico, Italy, United Kingdom, Belgium, Israel, Venezuela, Thailand, Angola, Estonia, Belarus, Brazil, Taiwan, Pakistan, Hungary, Vietnam, Australia, Afghanistan, Algeria, Kazakhstan, Gabon, Mexico, Poland, Bahrain, Malaysia, Greece, Macau, Chile, Singapore, Colombia, Oman, Chile, Namibia, Ukraine, Ghana, Argentina, India, Egypt

Ansi b16.5 Flanges traders, prime quality Ansi b16.5 Flanges, Source for Ansi b16.5 Flanges, specialize in Ansi b16.5 Flanges, Ansi b16.5 Flanges with Test Certificate, Ansi b16.5 Flanges at dealer price, Ansi b16.5 Flanges in India , Ansi b16.5 Flanges Prices in India , Stainless Steel Pipe Fittings Stockist in India , Ansi b16.5 Flanges Supplier in India , Ansi b16.5 Flanges Exporter in India , Ansi b16.5 Flanges Manufacturer in India , Ansi b16.5 Flanges Distributor in India , Ansi b16.5 Flanges Trader in India , Ansi b16.5 Flanges Dealer in India , Ansi b16.5 Flanges Stockholder in India , Ansi b16.5 Flanges Importer in India. , Ansi b16.5 Flanges distributor in Mumbai , Ansi b16.5 Flanges with Test Certificate , Ansi b16.5 Flanges Manufacturer in Mumbai,Ansi b16.5 Flanges, best quality Ansi b16.5 Flanges, India’s largest Ansi b16.5 Flanges manufacturer, wide variety of Ansi b16.5 Flanges, Ansi b16.5 Flanges India, Ansi b16.5 Flanges distributor Mumbai

Material

WNRF Flange weight chart

ANSI B16.5 Flanges Manufacturers in India

India's Most Experienced Manufacturers,Suppliers and Exporter of Ansi b16.5 Flanges, Ansi b16.5 Weld neck Flanges, Ansi b16.5 Slip on Flanges, Ansi b16.5 Socket weld Flanges, Ansi b16.5 Blind Flanges, Ansi b16.5 Lapped joint Flanges, Ansi b16.5 Threaded Flange, Ansi b16.5 Plate Flange in India & Uk
